Friction Saw Blade Sharpening Machine
Main Features:
1.The saw blade grinder SKD11 is mainly made in high-carbon steel, it has been heat-treated and grinded. Besides, its pushing arm spring has been improved by using the rotary spring, so that flexibility fatigue rarely happens and ensures the accurate feed.
2. Friction saw blade grinding machine uses computer to simulate and design the industrial-class professional tooth profile cam in order to make the grinding simpler, faster and more accurate.
3. Friction saw blade grinders help you easily operate the machine by using the vertical grinding method.
After years of research and development, a professional-level friction type saw blade grinding machine was designed. Its advantages includes the adjustment rod arrangement, the reasonable arrangement of rod makes the operator to easily adjust the tooth cutting angle, the backlash angle, tooth depth and tooth pitch. Furthermore, the thickness adjustment of saw blade, which obtained patent in many countries, that the blade was hold by two moving devices at the same time and move to the central of the machine for grinding; thus, there is no requirement to manually adjust the thickness of the blade. And it also can reduce the grinding noise.
Parameters:
| Model | SU-1200 | |||||
| Diameter of saw blade | 200mm-1200mm | |||||
| Tooth pitch | Max 25mm | |||||
| Thickness of saw blade | 8mm Under | |||||
| Sharpening speed | 10-100teeth/min | |||||
| Diameter of grinding wheel | 150mm-220mm | |||||
| Grinding wheel motor | 1/2HP | |||||
| Transmission motor | 1/2HP | |||||
| Grinding wheel speed 50HZ/60HZ | 3800RPM/4500RPM | |||||
| Weight(KG) | 260KG | |||||
| Dimension(L×W×H)mm | 820×1150×1840 | |||||
| Voltage | 3 phase 380V 50HZ or as per request | |||||
Machine Photo :
Certificate :
Company Profiles :
with decades hard work and accumulated experiences, We have acquired fourty invention
patent,Utility model and appearance patent.Meanwhile, We have passed ISO9001:2008 quality system certificate, Government-issued Guangdong Province private technology enterprises, high-
tech enterprises, private enterprises and other honors.
The products include Super hard metal bar cold saw machine series, Chipless metal pipes circular saw machine series,Copper aluminum non-ferrous high-speed precision circular saw machine series,Metal pipe/bar end chamfer machine series,Circular saw blade sharpening machine series,Automatic pipe bending and forming Machine series , Six categories eighty models , Also provide customized complex process
Machine , all kinds of circular saw blade . Wide Application range contains Nautical
aviation and aerospace industry, military industry, high-speed rail and rail transportation
industry, auto industry, precision parts, medical and fitness equipment industry, mechanical and electrical and electronic industry, lighting and furniture decoration forty industries .
