Aluminum Window Door Single Head Cutting Saw
- 30 Set / Sets per Month
- Qingdao
- T/T Credit Card
You May Like
-
new aluminium window making machine
-
High efficiency end milling machine for aluminium doors windows
-
6000mm length aluminum profile CNC double head cutting saw
-
aluminium crimping machine for windows doors / aluminium window door manufacturing corner crimping machine
-
Alu-alloy Multi-Function Single Head Saw
-
China 15 Mpa pressure corner crimping machine for aluminium window door frame fabrication
Product Details
Brand Name | PARKER |
Product Description
Single head cutting saw machine for Aluminum
If the above product is not your cup of tea?
Never mind,please click here,leave product name you need
You will find more solutions.
LDJ135 multi-function single head saw is not only used for cutting aluminum alloy curtain wall and window profiles, but also applicable for cutting plastic materials. Its hard alloy saw blade diameter can reach 16 inches. This single head cutting saw is also equipped with positioning rack. Digital display device can be installed on the machine depending on customers' requests. It can realize accurate positioning. The saw head of the multi-function single head saw can swing between 90° and 45°. Our products are well received for high quality control, competitive price and acceptable small order. Therefore, Parker single head cutting saw is an ideal choice for cutting different angles of aluminum doors and windows and curtain walls profiles.
Model | LDJ135 Multi-Function Single Head Saw |
Repeating Fixed Length Precision | ≤ 0.3 mm |
Cutting Angle | ± 5′ |
Cutting Plane | ≤ 0.1 mm |
Cutting Harshness | Ra 12.5 µ m |
Power Supply | 380V 50 Hz (Three Phase, Four Wire) |
Motor Power | 2 × 1.5 kW |
Rotary Speed | 2800 rpm |
Trailer Speed | 1400 rpm |
Air Pressure | 0.5 to 0.8 Mpa |
Cutting Length | Max. 120 mm Min. 60 mm |
Cutting Width | Max. 120 mm |
Cutting Height | Max. 80 mm |
Feeding Speed | 0 to 3 m/min (Variable Speed) |
Saw Blade Dimension | Φ300 × 2.8 × Φ30 × Z100 |
Overall Dimension | 700 mm × 780 mm × 1310 mm |
Weight of Multi-Function Single Head Cutting Saw | 120 kg |
1. The single head cutting machine is quite suitable for PVC and aluminum profile cutting.
2. This single head cutting saw is easy and convenient to operate and maintain.
3. It adopts high quality imported hard metal saw blade, which ensures high cutting accuracy and high cutting efficiency.
4. The multi-function single head saw is also featured with compact structure and small volume.
5. Parker multi-function single head cutting saw is equipped with a sliding table to support long profiles
Founded in 2003, Parker Machinery Co., Ltd has developed an assembly line for door, window, curtain wall and insulating glass equipment. With over ten years' production experience, Parker has become a leading manufacturer of window door machinery in China. The operation of high precision, advancement and specialty ensure that we are able to supply high-quality window and door equipment for customers.
During the past few years, Parker has made great progress and has become well known and outstanding in domestic fairs for window door machinery. With advanced technological equipment, tremendous technical strength and reliable product quality, our window and door equipment has been well received by customers from Russian, Kazakhstan, Vietnam, Iran, etc. We have a perfect sales network and complete service system in China. We are also taking a leading role in setting branch companies abroad.
