Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 From Parker China

Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 From Parker China photo-1
Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 From Parker China photo-2
Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 From Parker China photo-3
Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 From Parker China photo-4
Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 From Parker China photo-5
Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 From Parker China photo-6
US$ 20,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Parker
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO CHINA any port (EXW FOB CFR CIF etc)
Delivery Detail:
Delivery time depends on order quantity.
Brand Name Parker

Manufacturer of Any Angle CNC Double Head  Mitre Saw Cutting Machine A8-500 from Parker China   Aluminium profile cutting machine, aluminium doors window manufacturer,aluminium window frame making machine,aluminium punching machine,aluminium door and window making machine,aluminium double head cutting machine





Product Description



Double Head Mitre Saw Cutting Machine:Model:Model: A8-500
Features:
  • The machine is the most advanced double-head cutting saw.
  • The control system adopts the new closed-loop system, and can ensure the accuracy of repeat length.
  • The imported blade with high precision makes the cutting surface smoothly.
  • The servomotor drives the speed reducer to adjust the cutting angle in 45°-157.5°.
  • The imported control system can ensure the cutting quality.
  • Several profile processing dimensions can be input one time and make continuous cutting.
  • The imported service motor with high moving speed and high precision should drive the sawing head.
  • The machine has label printing function (option).

Parameter:

  • Voltage:

380V   50HZ

  • Power:

6.8KW

  • Air pressure:

0.5-0.8MPa

  • Blade specification:

500mmx30mmx4.4mm z=120

  • Cutter moving speed:

0-2m/min

  • Cutting length:

Max5000mm   Min480 at 90°

Max5000mm   Min(double height of profile) at 45°

  • Cutting width:

120mm

  • Cutting height:

230mm

  • Cutting angle:

45°-157.5°

  • Repeat locating length error:

+-0.2mm

  • Surface plainness:

+-4

  • Overall dimension:

6800mmX1500mmX2040mm



 Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 from Parker China



Company Information




Parker Machinery Co., Ltd
 is a leading supplier and exporter of door and window making machine in China.



 We mainly provide aluminum profile Machine:

1)Aluminium window door frame machine :CNC cutting machine,

2) insulating glass processing machine.

3)PVC window and door machine

4)3Axis,4Axis CNC Drilling and Milling Machine Center       curtain wall equipment, and so on.

Complying with European standards, we always purchase main parts internationally.

 Our machinery has passed CE and UL certifications.

They are exported to over120Countries and regions, such as North America, East Europe and the Middle East

 Aluminium Window Door Machine,Aluminium profile Saw Cutting Machine,Aluminium Window door frame Corner Crimping Machine, Window door Punching Machine, 3 Axis 4 Axis Machine center/ Milling and Drilling machine,China Aluminium Door Making machine, Window door Fabrication Machine.



Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 from Parker China



 Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 from Parker China

2)Our Factory Advantage :



1)Over 13 years factory experience in this line



Parker Machinery Co.,Ltd China. who established in 2003 year,we own 13years experiences,



We have a large group of good quality with good price parts supplier: Aluminum Window Door Making Machine,PVC Window door making machine, Insulating Glass Production Line, CNC milling and drilling machine center.They are stable and very cooperated due to our big factory strength.



2)Professional/Advance Production lines with professional workers!



 6 Production machine lines for our product which have been get patented Invented.and 24 hours work time for our customer



 3).The stable annual output



The stable output was upon the stable quality,This can only be achieved through innovative research



and developments together with decades of experience on countless brewery projects all over the world.



4).Our factory workers and service team was very powerful and professional.



We always can meet your requirements upon our tech and service.



 The large group of tech and service team will meet you around 24 hours.we have our professional



5).We have our own brand “PARKER"OEM/ODM acceptable



In the past 13ears,our own brand "PARKER"have high reputation among local and abroad.



we have our agent in Europe, South America,North America and Asia,



We will search more higher agent around the globe.



Our Services



1. One year warranty time, we can repair and replace parts for free in one year.

2.Technical support in 24 hours online, TM, Skype, E-mail, solving the relative questions in time.

3. Free maintenance service.

4. Free training course at our factory with professional engineers.
5. We provide the consumable parts at agent price when you need replacement.

6. Engineer available overseas.





1. When can we arrange shipment?



We usually arrange shipment in 15 days after getting deposit, but customized machines should be more than 25 days.



2. What to do if you get problems with the machine?



a. We will send you free spare parts if your machines are in guarantee time.



b. We can send our engineers to repair your machines.







Any Angle CNC Double Head Mitre Saw Cutting Machine A8-500 from Parker China
