DMCC6 Aluminum Profile 4 Axis CNC Machining Center for Drilling Milling
- T/T Credit Card
You May Like
-
Aluminum CNC Machining Center for Drilling Milling Curtain Wall Window Door
-
Industrial Aluminum Profile 4 AXIS CNC Machining Center
-
3 Axis CNC Machining Center for Curtain Wall Industrial Aluminum Drilling Milling Threading
-
Aluminum Curtain Wall 4 Axis CNC Machining Center for Drilling Milling
-
Aluminum Heat Sink Automatic Drill Mill Machine
-
Aluminum Curtain Wall Profile Parker Machinery for Curtain Wall Project
Product Details
| Brand Name | Parker Machinery | Place of Origin | Shandong, China | |
| Type | Vertical | Certification | ce | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | one year | |
| Weight | 4.5T | Dimension(L*W*H) | 10100x2300x2600mm | |
| Voltage | 380v 50hz | Condition | New | |
| Power(W) | 10KW |
Product Description
DMCC6 Aluminum Profile 4 Axis CNC Machining Center for Drilling Milling
4-Axis Machining Center
DMCC6
Features:
1.The machine is suitable for processing installation holes, water slot, shaped holes, and end milling and making screw on curtain walls and aluminum windows and doors.
2. It adopts high-speed electric principal axis, which is imported from Italy. It is extremely efficient and can swing in±90°
3.It adopts high-quality computer control system which is used in industry area specially, with good user interface, graphical programming and processing tracking interface, truly realize what you see and what you get.
4. It adopts high-quality servo motor, ball screw, linear guide pair and bearings and so on to ensure the machine runs with high precision.
5. Equipped Six cutters positions, the cutter can change quickly and automatically .
6. The semi-closed guard improved security greatly.
7. Clamping device position can be optimized and put to right position automatically and freely.
Technique Parameter:
X- axis:7600mm
Y- axis:960mm
Z- axis:610mm
X- axis speed:0~90m/min
Y- axis speed:0~80m/min
Z- axis speed:0~75m/min
Main shaft rotary range: - 90º ~ 0º ~ + 90º
Tool magazine:6 different cutters, change cutter automatically
Max cutter length: 165mm
Air Pressure:0.5-0.8Mpa
Voltage:380V/50Hz
Total power:10kw
Number of clamping device: 8
Lubrication and cooling : Lubricating automatically, spray cooling
Processing size range(WXHXL):550×300×7300mm
Overall dimension:10100×2300×2600mm

1.One year warranty time, we can repair and replace parts for free in one year.
2.Technical support in 24 hours online, TM, Skype, E-mail, solving the relative questions in time.
3.Life time free maintenance service.
4.Free training course at our factory with professional engineers.
5.We provide the consumable parts at agent price when you need replacement
Founded in 2003, Parker Machinery Co., Ltd has developed an assembly line for door, window, curtain wall and insulating glass equipment. With over ten years' production experience, Parker has become a leading manufacturer of window door machinery in China. The operation of high precision, advancement and specialty ensure that we are able to supply high-quality window and door equipment for customers.
During the past few years, Parker has made great progress and has become well known and outstanding in domestic fairs for window door machinery. With advanced technological equipment, tremendous technical strength and reliable product quality, our window and door equipment has been well received by customers from Russian, Kazakhstan, Vietnam, Iran, etc. We have a perfect sales network and complete service system in China. We are also taking a leading role in setting branch companies abroad.

1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: Where is your factory located? Can I visit there?
Our factory is located in Jinan City, Shandong Province, China, near to Jinan and Qingdao. You are warmly welcomed to visit us!
3. Q: How does your factory do regarding quality control?
We have strict control in testing of raw material, production process and final process. Only qualified products can be sent out.And we have passed ISO,CE certificate.
4.Q:What you can do if my machines have problems?
a.We can send you free components to you if your machines are in guarantee time.
b.We can send our engineers to repair your machines
5. Q: If OEM available?
Answer: Yes, as we usually do.
6. Q: What are your company normal payment Terms?
Answer: We accept T/T (30% T/T prepaid before production, 70% T/T prepaid before shipment)
