CNC Drilling And Milling Machine For Aluminium Extrusion Profiles

Name: CNC Drilling And Milling Machine For Aluminium Extrusion Profiles
Brand: PARKER
Availability: InStock

FOB Price

US$ 25,000 - 45,000 / Unit

1 Unit(Min. Order)

Port Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

PARKER

Product Description

CNC Drilling And Milling Machine For Aluminium Extrusion Profiles

Features:

1.The machine is suitable for processing varieties of holes and slots for diversified aluminum doors and windows.

2. It adopts high-precision linear guide pair, ball screw, pinion and rack and imported servo motor to ensure the machine runs steadily with high precision.

3. It adopts Italian HSD high-speed motorized spindle to ensure the machine runs steadily with lower noise and better cutting ability.

4.It adopts vegetable oil microcrystalline cooling system to improve the tool life without poison and pollution.

5.The rotary workbench can change the position among -90°,0° and +90° arbitrarily, one time clamping can finish milling for three sides.

6.It adopts PA control system from Italy, intelligent CNC control system and straightforward human-computer interface make the operation much more convenient and efficient.

7.Application:Aluminum Architecture Material/PVC Window Door Profiles/Wooden Profiles /Curtain Wall and Facade Lock Hardware etc.

Parameter:

X axis Stroke	3200mm
Y axis Stroke	300mm
Z axis Stroke	200mm
X axis Speed	0~140m/min
Y axis Speed	0~75m/min
Z axis Speed	0~75m/min
Main spindle speed and Power	18000rpm/3kw
Work table position	-90°,0°,+90°(Three degree)
Cutter size	ER25-8(Without Cutter or Within Storage and Max. Four Cutters)
Air Pressure	0.5~0.8MPa
Voltage	380V/50Hz
Power	6kw
Cutter cooling	Auto spraying and cooling
Processing dimension:(W×H×L)	160×160×3200mm
Processing character	Can process three sides of profile per time loading profile
Dimension:(L×W×H)	4525×1630×1900mm

PARKER IS DEVELOPING WITH THE WORLD.

Parker was founded in 2003, since the entry into the window door curtain wall machinery manufacturing field, peck with the best team and most stringent manufacturing standards, has been committed to the global supply of machinery and the best service. Today, with more than 300 employees, Parker Industrial Park covers an area of 70000 square meter, Parker has become Chinese and even the world's window door curtain wall and insulating glass high-end machinery manufacturing base.

FAQ

Q: How can I get the best machine for our business?

A: Just let us know your cutting material, size, thickness, and working area needed, we will suggest the most suitable machine and professional solution.

Q: When can we arrange shipment?
We usually arrange shipment in 15 days after getting deposit, but customized machines should be more than 25 days.

Q: This is my first time using this kind of machine, is it easy to operate?
A: Of course the machine is easy to operare. We will send you the English version user manual and install video which shows how to assamble and use the machine clearly, almost all the customers can operate the machine easily. No need to worry about this, after all, Parker will always be here to help!

Q: If the machine has problem in my place, how could I do?
A: Usually there won't be any problem under "normal use" as per the user manual. But in case you have any problem, our professional after-service team will provide you any support you need any time!

B.We can send you free components to you if your machines are in guarantee time.
C.We can send our engineers to repair your machines.

Q: This machine is not suitable for me, do you have more models available?
A: Sure, in order to meet different customers' different requirments, we reserched many other different machines.
