Insulating Glass Processing Vertical Glass Washing and Drying Machine

Insulating Glass Processing Vertical Glass Washing and Drying Machine thumbnail-1
Insulating Glass Processing Vertical Glass Washing and Drying Machine thumbnail-2
Insulating Glass Processing Vertical Glass Washing and Drying Machine thumbnail-3
Insulating Glass Processing Vertical Glass Washing and Drying Machine thumbnail-4
Insulating Glass Processing Vertical Glass Washing and Drying Machine thumbnail-5
Insulating Glass Processing Vertical Glass Washing and Drying Machine thumbnail-6
Insulating Glass Processing Vertical Glass Washing and Drying Machine photo-1
Insulating Glass Processing Vertical Glass Washing and Drying Machine photo-2
Insulating Glass Processing Vertical Glass Washing and Drying Machine photo-3
Insulating Glass Processing Vertical Glass Washing and Drying Machine photo-4
Insulating Glass Processing Vertical Glass Washing and Drying Machine photo-5
Insulating Glass Processing Vertical Glass Washing and Drying Machine photo-6
US$ 7,980 - 11,250 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
TRUEPRO
Place of Origin:
Shandong, China
Certification:
CE
Contact Supplier Request Quote Chat Now
Dafei Weiye Industrial & Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name TRUEPRO
Place of Origin Shandong, China
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 12 Months
Weight 2500Kg
Dimension(L*W*H) 7000*2100*3000(mm)
Production Capacity 100%
Condition New
Voltage 380V 50HZ
Power(W) 15kw
Machine Type Glass Washing and Drying Machine
Product Description

Vertical glass washing and drying machine with high quality for insulating glass processing

Product Application

It is used for the glass washing and drying.

Main Features

1. Washing section and water system adopt complete satinless steel or rotproof material.

2. It has excellent effect on washing and drying.

3. Drying section adopts rubbers roller to scrape off the water,and use the hot wind to dry the glass.

4.The transmit system of washing machine adopts unlimited speed adjustment to realize high efficiency of application.

Input power
15kw
Air pressure
0.5~0.8MPa
Power supply
380V 50Hz
Max. glass size
1800*2500mm
Working direction
right to left/left to right
Min. glass size
280*450mm
Glass thickness
3-18mm
Washing speed
0-8m/min
Weight
2500kg
Overall Dimension
7000*2100*3000mm
Machine Processing

We work with everything from raw material to final machine, could guarantee machine quality from each step. select each part carefully, we are strive to quality first when machine production and test each machine before delivery.
We will provide the best machine for you.

Packing & Delivery
Certifications
Our Service

Pre-Sales Service

* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.

Payment

* L/C, 30% deposit by T/T,70% spare payment L/C.
* T/T, 30% deposit by T/T,70% spare payment before shipment.
* Western Union or Paypal.

Company Information

Welcome To Visit

Exhibitions
FAQ

Question 1: Are you manufacture?

Answer: Yes, we are the professional manufacture which have more than 5 workshops.
Question 2: About this Machine,What’s the guarantee ?
Answer: 1).Our guarantee for 12 months.

               2).24 hour’s technical support by email or calling.

               3).English manual and video tutorial.

               4).We will provide the consumable parts at an agency price.

               5).24 hours on line service each day, free technical support.
Question 3: if our price is higher than another company or factories ?
Answer: please check, what is is the different of the machine of parts ,service and guarantee,especially the machine inner electric parts, sometimes,if the machine have breakdown, the most reason is the machine inner electric parts problem, but we use the famous and reliable parts for the machines inside.
