High Precision Automatic Used Machine for Cutting Aluminum Corner of Window and Door

Main Specification used machine for cutting aluminum

1) Max. length of profile: 300 mm
2) Mini. length of profile: 3 mm
3) Max. travel of sawing head: 90 mm
4) Blade diameter: Φ 450 mm
5) Blade aperture: Φ 30mm
6) Effective cutting length: 110 mm
7) Height of working stand: 1150 mm
8) Pneumatic working pressure: 0.5-0.8 MPa
9) Air consumption: 0.2 cubic m/min.
10) Blade feeding speed: 1-5 m/min.
11) Power of main motor: 3 kw
12) Rotational speed of spindle: 2800 rpm
13) Dimensions: 1150x2250x1450 mm
14) Weight: 500 kg

Cutting Precision used machine for cutting aluminum
1) Repetition on length: ± 0.1 mm
2) Repetition on angle: ± 5’
3) Verticality of cutting: 0.1 mm (100x100mm section)
4) Planeness of cutting surface: 0.1 mm (100x100mm section)
5) Roughness of cutting surface: Ra 12.5 µm
