Zoomlion 8 Cbm Used Concrete Mixer Truck K8JB-R With Hydraulic Pump
US$ 12,000 - 13,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
Zoomlion
Place of Origin:
Hunan, China
Certification:
ISO CE
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SANY Good Trailer Concrete Pump Truck HBT6013C-5SUS$ 130,000 - 260,000MOQ: 1 Unit -
China Hot Sale 16m3 BEIBEN 8X4 Concrete Mixer Truck PriceUS$ 35,000 - 50,000MOQ: 1 Unit
-
SINOTRUCK HOWO 8x4 Concrete Mixer Truck PriceUS$ 35,000 - 50,000MOQ: 1 Unit
-
Cost Effective HOWO 8x4 10m3 Concrete Mixer Truck for SaleUS$ 35,000 - 50,000MOQ: 1 Unit
-
8m3 Concrete Mixer Truck SANY 6x4 With Improved Braking TechnologyUS$ 35,000 - 50,000MOQ: 1 Unit
Brand Name
Zoomlion
Place of Origin
Hunan, China
Certification
ISO CE
Warranty
1 Year
Weight
4590 kg
Dimension(L*W*H)
6925*2490*2795 mm
Condition
New
Zoomlion 8 cbm Used Concrete Mixer Truck K8JB-R with Hydraulic Pump
Product Description
• Double Logarithmic Variable Pitch Helical Mixer Blade: which enables higher charing and discharging speed and even mixing, eliminates segregation of concrete and is suitable for the transportation of both dry and wet materials.
• New T-shape Blade technology. It is made of hard-wearing alloy steel, and thus protects the mixer blades from abrasion, extends the service life of the agitator drum, and enhances mixing performance.
• The geometric capacity of the agitator drum is very large and the filling rate is low, thus guaranteeing more mixing space. The small inclined angle and low center of gravity help reducing the possibility of turning-over of the truck.
• Closed loop hydraulic system and constant hydraulic oil temperature controller. Key hydraulic accessories including: Hydraulic plunger pump, adjuster mechanism with servo, hydraulic motor, and planetary reducer, all of which are manufactured in world-known brands with stable and reliable performances.
• Pneumatic Water Supply System: The pressure is provided by the air tank on the chassis with pressure protection devices. The pressure is provided by the air tank on the chassis with pressure protection devices. The water inlet connector fits for both normal water pipe and fire fitting.
• Multi-outlet washing design of which the cleaning requirements are met with the three fixed pipes for washing the agitator drum, charging hopper and discharging hopper respectively, and another flexible water outlet.
• Three-point operation system: One in the cab to allow control of the agitator drum, to turn forward and reverse, and to perform the “feed”, “discharging”, “agitate” and “stop” functions. Two at the rear with one operation handle at each side to perform “charge”, “accelerate”, “discharge”, “agitate” and “stop”, all of which are interlocked.
• New T-shape Blade technology. It is made of hard-wearing alloy steel, and thus protects the mixer blades from abrasion, extends the service life of the agitator drum, and enhances mixing performance.
• The geometric capacity of the agitator drum is very large and the filling rate is low, thus guaranteeing more mixing space. The small inclined angle and low center of gravity help reducing the possibility of turning-over of the truck.
• Closed loop hydraulic system and constant hydraulic oil temperature controller. Key hydraulic accessories including: Hydraulic plunger pump, adjuster mechanism with servo, hydraulic motor, and planetary reducer, all of which are manufactured in world-known brands with stable and reliable performances.
• Pneumatic Water Supply System: The pressure is provided by the air tank on the chassis with pressure protection devices. The pressure is provided by the air tank on the chassis with pressure protection devices. The water inlet connector fits for both normal water pipe and fire fitting.
• Multi-outlet washing design of which the cleaning requirements are met with the three fixed pipes for washing the agitator drum, charging hopper and discharging hopper respectively, and another flexible water outlet.
• Three-point operation system: One in the cab to allow control of the agitator drum, to turn forward and reverse, and to perform the “feed”, “discharging”, “agitate” and “stop” functions. Two at the rear with one operation handle at each side to perform “charge”, “accelerate”, “discharge”, “agitate” and “stop”, all of which are interlocked.
Main Parameters
| Model | ZOOMLION K8JB-R | ||
|---|---|---|---|
| Structure Parameter | Upper Structure Mass | kg | 4590 |
| Dimensions(L×W×H) | mm | 6925×2490×2795 | |
| P.T.O Type | Engine P.T.O | ||
| Water Supply Type | Air Pressure Type | ||
| Volume of Water Tank | L | 450 | |
| Air Tank Joint | M22×1.5 | ||
| Drum Performance Parameter | Agitator Capacity | m3 | 8 |
| Gradient of the Drum | o | 13 | |
| Max Speed of the Drum | rpm | 12~16 | |
| Charge Speed | m3/min | ≥4 | |
| Discharge Speed | m3/min | ≥3 | |
| Remnant Ratio of Discharging | % | ≤0.7 | |
| Range of Slump | mm | 50~210 | |
| Hydraulic System | Pump | REXOTH Dextrorotatory A4VTG090 or others | |
| Motor | REXOTH AA2FM80 or others | ||
| Gear Box | P4300 or others | ||
| Hydraulic Circuit | Closed | ||
