300HP 26Ton Operating Weight GR300 Motor Grader With CE Certificate
US$ 26,500 - 27,500
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
NEWINDU
Model Number:
GR300
Certification:
ISO CE
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
15Tons 165HP Articulated Motor Grader GR1653US$ 56,000 - 57,000MOQ: 1 Unit -
Made in China Cheap Small Motor Grader for SaleUS$ 55,000 - 56,000MOQ: 1 Unit
-
2018 New 16Ton Road Roller With Good PriceUS$ 30,000 - 31,000MOQ: 1 Unit
-
New Vibratory Tamping Roller 16 Ton Road Roller XP163US$ 35,000 - 50,000MOQ: 1 Unit
-
Low Price Used XD81E Road Roller for Sale in IndiaUS$ 30,000 - 32,000MOQ: 1 Unit
Brand Name
NEWINDU
Model Number
GR300
Certification
ISO CE
After-sales Service Provided
Engineers available to service machinery overseas
Weight
26000kg
Dimension(L*W*H)
10500*3100*3550
Condition
New
Reverse Speed(km/h)
23
Forward Speed(km/h)
38
300HP 26Ton Operating Weight GR300 Motor Grader with CE Certificate
Please Contact
Aring Zhou
Email: aring at
Skype:zyy1520724641 at
Wechat/Whatsapp/Mobile:+86 15855426352
Main Parameters
Basic Specification
| Model | GR300 |
| Engine Model | QSL9 |
| Rated Power/Speed | 224/2100kw/rpm |
| Dimension(L*W*H) | 10500*3100*3550mm |
| Operating Weight | 26000kg |
Main Performance
| Travelling Speed(forward) | 5,8,11,19,23,40km/h |
| Travelling Speed(reverse) | 5,11,23km/h |
| Tractive Force(f=0.75) | 140kN |
| Max.Gradeability | 30% |
| Tire Inflation Pressure | 350KPa |
| Working Hydraulic Pressure | 16MPa |
| Transmission Pressure | 1.3-1.8MPa |
Operating Specification
| Max. steering angle of front wheels | ±50° |
| Max. lean angle of front wheels | ±17° |
| Max. oscillation angle of front axle | ±15° |
| Max. oscillation angle of balance box | 15 |
| Frame articulation angle | ±27° |
| Min. turning radius using articulation | 8.0m |
Biade
| Maximum lift above ground | 450mm |
| Maximum depth of cutting | 500mm |
| Maximum blade position angle | 90° |
| Blade cutting angle | 28°-70° |
| Circle reversing rotation | 360° |
| Moldboard width X height | 4920*787mm |
