Home > Products > auto scanner > OPCOM V1.99 V1.95 V1.78 V1.70 V1.65 OBD2 CAN-BUS Code Reader For Opel OP COM OP-COM obd2 Diagnostic PIC18F458 FTDI Chip
OPCOM V1.99 V1.95 V1.78 V1.70 V1.65 OBD2 CAN-BUS Code Reader For Opel OP COM OP-COM obd2 Diagnostic PIC18F458 FTDI Chip
- 1000 Piece / Pieces per Month
- SHENZHEN
- T/T PayPal Other
- 4 days
- Professional universal auto diagnostic scanner FCAR F3-G Car & Trucks Universal Diagnostic Scanner
- Hot Sale Original vehicle diagnostic equipment Fcar F3-G professional car and truck universal car diagnostic tool
- Universal Truck Diagnostic Tool fcar F3-G diesel and gasolin car diagnostic scanner for Japan,korea,Europe,America Cars
- Original Multi-functional English/Russian Version Fcar Universal truck diagnostic tool 24V diesel truck diagnostic scanner
- used car diagnostic scanner F3-G Global Car and Truck Diagnostic Scanner
- Original Fcar F3-G Automotive Diagnostic Scanners for 12V+24V Cars and Heavy duty trucks
Product Details
Brand Name: | autodiagtech | Place of Origin: | China | Model Number: | op-com |
Type: | Code Reader | Certification: | CE | Power: | 24 |
Warranty: | 1 | Applicable Models: | op-com |
Product Description
OPCOM 2012 diagnostic tool for Opel cars covers almost all for Opel cars, even new cars with CAN-BUS based diagnostic, such as for Vectra-C,for Astra-H,for Zafira-B. It lets you read and clear fault codes, support many control units.
Latest firmware version: V1.78
Opcom OP-Com 2014 V Can OBD2 for Opel Firmware V1.78 with PIC18F458 Chip
New OPCOM V1.78 Firmware 2014V Software Feature:
1. OPCOM is a special PC Based diagnostic interface especially for OPEL.
2. Software Version: 2014 Firmware Version: 1.78
3. Never Update It Online, It Will Damage The OP-COM
Attention for Latest Opcom Software VAUX-COM_120309a.exe:
1. If you run it on XP or Win7, please make sure you install dotnetfx35_SP1 system patch, or Opcom software can't perform well
2. When you install on Win7 and open software, please choose Run as administrator, and read the installation video on CD carefully
Please do not update this one online.
New OPCOM V1.78 Firmware 2014V Software Function:
1. It covers almost all for Opel cars, even new cars with CAN-BUS based diagnostic, such as for Vectra-C,for Astra-H,for Zafira-B.
2. The program lets you to read out and clear fault codes, shows you live data, lets you to perform output test.
3. The program supports many control units, like Engine, Automatic Transmission, ABS, Airbag, Engine Cooling module, Instrument Cluster, Electronic Climate Control, Body Control Unit, just to name a few examples.
4. Since for Opel uses many pin in the OBD connector, the diagnostic interface works as a multiplexer, and selects the appropriate pin for communication.
PIN3, PIN7, PIN8, PIN12 = Serial Link (ISO9141, KW81, KW82, KWP2000)
5. Fault codes will be shown with all available information:
Full Fault Code Text Description:
1) Full status information (Present, Not present, Intermittent)
2) You can print out, save, or copy the fault codes to any other application. From the fault codes window, you can go directly to the measuring blocks window.
3) The program shows you measuring block information on many control module, you can choose anything from the list on your own.
4) The program is capable of showing 8 measuring block parameter simultaneously. The sample rate is depends mostly on the communication protocol. For example, older system, like Omega-B X 25 DT Engine (ISO-9141-2) can be very slow, during communication, while newer Multec, or for Bosch units are faster (using KWP-2000), and the newest CAN based control units are very fast!
You can also run output tests on many controllers.
PIN6-PIN14
PIN3-PIN11
PIN1
HSCAN - Dual-wire, High Speed CAN-BUS, 500 kbps
MSCAN - Dual-wire, Medium Speed CAN-BUS, 95 kbps
SWCAN - Single-wire, Low Speed CAN-BUS, 33.3 kbps
