I. The brief description of wood chip crusher
♦ The disc type wood chip crusher is one professional machine for producing high quality wood chips. It's applicable to paper mill, shaving board factory, fibreboard factory and other wood chips processing machinery.
It can cut the round raw wood into uniform length and thickness, flat incision wood chips.
♦ The large type disc wood chip crusher can with belt pulley drive or direct-connected drive, the feeding can be level or incline, the output port can be above or bottom. The disc type wood chipper machine can be with capacity from 2~160m3 per hour.
♦ The disc type wood chip crusher consists of mainframe,seat, cutter disc, feed inlet port, shell, electric control system, etc.
II. Working principle of wood chip crusher
♦ The raw wood input through feeding port, the wood will be chipped by high-speed revolution cutter, the wood chips will be output by high speed airflow.
♦ The disc type wood chip crusher can cut the round raw wood less than 200mm, there will be different based on different model machine.
Model 型号 |
FD950 |
FD1710 |
FD1212 |
FD1300 |
FD1216 |
FD1680 |
|
刀盘直径 Diameter of Disc (mm) |
950 |
1000 |
1220 |
1300 |
1600 |
1650 |
|
飞刀数量 Number of knife (pc) |
6 |
6 |
6 |
4 |
6 |
4 |
|
进料喂料 Feed inlet (mm) |
220*210 |
230*220 |
350*350 |
350*350 |
545*383 |
500*500 |
|
加工最大直径 Maximum processing diameter (mm) |
200 |
200 |
300 |
300 |
300 |
500 |
|
木片长度 Length of wood chip (mm) |
25-40 |
20-30 |
20-35 |
60-100 |
25-45 |
25-45 |
|
主电机 Main motor power (kw) |
55 |
55 |
110 |
132 |
220-250 |
160-200 |
|
产量 Capacity (m³/h) |
6-8 |
8-10 |
10-15 |
15-20 |
15-20 |
15-25 |
III. Advantage of wood chip crusher
♦ Security and durable.
♦ Low investment and energy consumption.
♦ High output.
♦ High-quality finished products.
♦ Easy to operate and maintain.
V. Final products
Pre-sales Service |
After-sales Service |
|
* Before sending the machine, we will test and adjust, so you can use directly when you get it. * Operation instruction will be sent to clients, to help them use better. * Provide professional and good service. * Provide high quality products with best price.* Customize the machine according to clients special requirements. * Visit our factory. |
* All products purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free. * Additionally, our company provides technical support and fittings for life. *After-sales service isn't restricted by time and we will solve your problems in time. If you are caught in some problems when using our products, welcome to contact us at any time. |
