Disc wood chipper
1. Disc wood chipper Characteristics
1) Reasonable structure,
2) Wide usage, High output
3) Qualified chips, Safe and reliable
4) Easy operation, Easy maintenance
2.Disc wood chipper Using scope and purpose
1). Scope: small logs, wood cutting residues.
2). Purpose: Preparing raw material for density board plant and paper-making plant, etc.
3. Disc wood chipper Technical parameters
Type |
HX1112 |
HX1212 |
HX1216 |
Blade rotational speed (rpm) |
740 |
740 |
620 |
Blade Qty (piece) |
6 |
6 |
6 |
Wood chips size (mm) |
20-35 |
20-35 |
20-35 |
Feeding method |
horizontal |
horizontal |
horizontal |
Input size (mm) |
400 x 275 |
350 x 350 |
420 x 420 |
Production capacity (TPH) |
10-15 |
13-18 |
15-25 |
Main power (kw) |
110 |
90 |
132-220 |
Output method |
Up down |
Up down |
Up down |
Disc diameter (mm) |
1220 |
1220 |
1575 |
Weight (Ton) |
4.58 |
4.25 |
5.58 |
Size (mm) |
3000x1570x1614 |
3000x1400x1614 |
3000x1170x2400 |
Type |
HX-1300 |
HX-1710 |
Input size (mm) |
350 X 350 |
230 x 230; 270 x 270 |
Blade Qty (piece) |
6 |
6 |
Main power (kw) |
55-75 |
45-55 |
Blade rotational speed (rpm) |
650 |
635 |
Feeding method |
Horizontal |
Horizontal |
Wood chips size (mm) |
20-35 |
20-35 |
Production capacity (TPH) |
15 |
8-12 |
Conveyor power (kw) |
5.5 |
3 |
Output method |
Down |
Down |
Max dia. of raw material (mm) |
300 |
200 |
Weight (Ton) |
2900 |
2180 |
Size (mm) |
2800 x 1250 x 1600 |
2500 x 1180 x 1250 |
4. Disc wood chipper Picture
5. Disc wood chipper High Quality Products
Introduction to Zouping County Hongxin Machinery
1).15 years of experience in biomass energy crushing industry, located in Zouping County, Shandong Province, China.
2).Main products: Wood chipper, Sawdust machine, Drum dryer, Vertical ring die pellet machine (biomass pellet machine), Counter flow cooling separator, Packing machine; Comprehensive crusher, Building templates crusher, Plancon crusher (Stump grinder), Free move (Mobile) cutting machine (Brush chipper), Complete pellet production line.
3).Manufacture independently the key machines of pellet production line, can design complete production line according to customers’ needs.
4).Covers an area of 40,000 square meters, with more than 200 people including 120 specialized technicians and 8 senior engineers.
5).More than 100 sets of machineries of assembling, processing and transportation, etc.
6).Formed a complete systematic management system, can offer non-standard products according to customers’ request.
7).ISO9001certified. CE certified.
8).Provide clients with reliable and timely After-Sales Service and Technology Support.
