Aluminum Alloy Automatic Machine CNC Cutting Machine
US$ 1 - 100000
/ Set
1 Set(Min. Order)
- Foshan
- T/T L/C
You May Like
-
CNC Full Automatic Aluminium Sheet Cutting Machine Factory Metal Laser Cutting Machine
-
Precision Automatic Aluminium Profile Cutting Machine Made in China
-
Popular Double Head Aluminum Window Door Miter Saw Cutting Fabrication Machine
-
Cnc Metal Automatic Laser Cutting Machine Automatic Cutting Machine
-
Cnc Metal Automatic Laser Cutting Machine Automatic Cutting Machine
-
CNC Servo Full Automatic Aluminium Tube Iron Cutting Machine
Product Details
| Brand Name | Haohongwei | Place of Origin | China | |
| Model Number | MJ885F | After-sales Service Provided | Engineers available to service machinery overseas | |
| Condition | New |
Product Description
Parameter：
| Product number | parameter | ||
| Weight | 1500kg | ||
| Cutting angle | 45º×2 | ||
| Transmission mode | High precision grinding rack | ||
| Pressing form | pneumatic | ||
| Feeding speed | 300mm/s | ||
| Feeding mode | CNC servo feeding | ||
| Spindle revolution | 3800r/min | ||
| Working Pressure | 0.6-0.8mpa | ||
| Working voltage | 380V+Zero line three-phase four line 50HZ | ||
| Saw blade size | Φ405×Φ25.4mm×3.4×120T | ||
| HJ885F | Corner sawing saw blade | Φ255×Φ25.4mm×3.0×120T | |
| CNC automatic 45o corner guard machine | Feed Servo Power | 0.75KW+0.4KW | |
| Outward Size | 3360x1300x1595mm | ||
| Main motor power | 2.2KW*2 | ||
| Reducer power | 1.1KW 1:50 | ||
| Cooling mode of saw blade | spray | ||
| Machining Length Accuracy | ±0.1mm | ||
| Max. sawing width | 105mm | ||
| Max. sawing height | 40mm | ||
| Control Conversion Mode | PLC touch screen | ||
| Angle protection motor power | 0.55kw×2 | ||
| Max. primary feeding length(segmented feeding) | 1200mm（Any length） | ||
