SCIENTZ-18NA Multi-manifold Gland Type Freeze Dryer

SCIENTZ-18N multi-manifold gland type freeze dryer

Features:

1. This machine adopts the international brand Secop (formerly Danfoss) compressor for refrigeration, which has rapid cooling and low cold trap temperature.

2, using 7-inch true color touch LCD screen control system, easy to operate, and powerful.

3, industrial embedded operating system, ARM9 core control circuit design, 32M memory 128M FLASH, fast operation response, large amount of stored data.

4. The control system automatically saves the freeze-dried data and can view it in the form of real-time curves and historical curves. The entire freeze-drying process is clear and clear.

5. The drying chamber adopts colorless transparent one-time injection molding polycarbon drying chamber, which is corrosion-resistant, non-fragile, non-adhesive, high in transparency, strong in airtightness, clear and intuitive in sample, and can observe the whole process of lyophilization.

6. The vacuum pump and the host are connected by an international standard KF quick connector, which is simple and reliable.

7. This machine can store multiple freeze-drying curves, and use U disk to extract data to the computer, use the host computer software to browse and print in the computer and various options.

8. Configure the inflation valve to fill the dry inert gas;

9. The cold trap temperature can be set and the vacuum pump can be turned on when the temperature is lower than the set value to protect the service life of the vacuum pump.

Technical Parameters:

Specifications: gland multi-manifold

Freeze-dried area (m2): 0.09

Water catching capacity (kg/batch) : 6

   Vial bottle

   Bottle filling amount Φ12mm 990

Φ16mm 349

Φ22mm 184

Number of eggplant bottles: 8

Ampoule interface (only): /

Plate loading solution (L): 1

Material plate size (mm): Φ200

Material tray spacing (mm): 70

Material plate size (pieces) : 3

Cold trap size (mm): Φ300×405

Cold trap minimum temperature (°C): ≤-56 (no load)

-80 °C cold trap minimum temperature (°C): ≤-80 (no load)

Ultimate vacuum (Pa): ≤ 5 (no load)

Power Kw (220V/50Hz): 1.3

Ambient temperature (°C) : ≤25

Overall dimensions (mm): 670(L)*525(W)*910(H)+480

-80°C overall dimensions (mm): 780(L)*525(W)*910(H)+480

Machine weight (kg): 87
