GT-2 Gloves Leak Detector (Offline)
- 100 Set / Sets per Month
- Shenzhen
- T/T Credit Card
Product Details
Brand Name: | SZHJKJ | Place of Origin: | Shaanxi, China | Model Number: | GT-2(S) |
Power: | Electronic |
Product Description
GT-2 Gloves Leak Detector (Offline)
Introduction:
The GT-2 Gloves Leak Detector is a leak detection device that specifically detects the integrity of gloves. It does not require any additional equipment, and the leak detection speed is fast, which reduces the number of inspection personnel and labor intensity, and improves production efficiency. The working principle of the GT-2 glove leak detector: the air is compressed by the air pump, and the compressed gas is driven into the glove through the electromagnetic valve. When the inflation pressure in the glove reaches the set value, the air pump stops working and the system begins to enter the pressure holding state. ;
The pressure holding process means that the pressure of the equipment is maintained at 1500 Pa or more within 30 seconds after the end of the inflation. That is, the glove is considered to be a qualified value, and the pressure holding curve graph is displayed on the display.
Features:
1. All stainless steel material is used, and the universal wheel is installed for easy transfer.
2. Color touch screen display, stable and reliable work, intuitive and simple interface
3. Can record and print the inspection process curve and test results
4. Detection period is 1min, which can quickly detect glove integrity
5. Available in 7-, 8-, 10-inch gloves, for a variety of sterile gloves
6. Optional 2-in-1 and 3-in-1 glove trays for testing a wide range of sterile gloves
7. Human-machine interface dialog box set three-level password management
8. The interface is simple and easy to understand, easy to operate
Technical Parameters:
Dimensions: 550*400*980mm
Detection period: 1min
Detection pressure error: ±1%
Weight: 12kg
Detection method: offline
Man-machine interface: touch screen
Head material: POM
Power supply: AC 220V/50Hz, 60w
