Introduction:
HK-3020ND automatic condensation point / pour point tester is mainly used to determine the condensation point and pour point of petroleum products, in line with GB/T 510-1983 "Determination of condensation point of petroleum products" and GB/T 3535-2006 "Dump of petroleum products Point method. The instrument uses a color LCD screen display, Chinese and English menus are available, no buttons, all human-computer interaction operations are completed by the touch screen, you can easily set the oil type, oil number, item selection, oil filling method under the prompt menu Other parameters, such as accurate measurement and easy operation, are widely used in the railway, aviation, power, petroleum and scientific research sectors.
Lubricants and dark petroleum products are cooled to the maximum temperature at which the liquid surface does not move under the specified conditions, and are called the freezing point. The measurement method is to install the sample in a predetermined sample tube and cool it to the desired temperature. After tilting the tube by 45° for 1 minute, observe whether the liquid surface is moving. The minimum temperature at which an oil and petroleum product sample can be cooled when it is cooled under specified conditions is called the pour point. The method of measurement is that the sample is preheated, cooled at a specified rate, and the fluidity of the sample is checked at intervals of 3°C. Record the lowest temperature at which the sample can flow as the pour point.
Features:
1. Adopt high-resolution color display, touch screen technology, with prompt menu-oriented input function
2. The use of high-performance semiconductor multi-level refrigeration technology, cooling speed
3. With chiller over temperature, cooling water under voltage automatic power protection
4 with fault self-diagnosis function
5. Using intelligent temperature control technology, fast intelligent measurement, good repeatability and high accuracy
6. With network port, USB interface, easy instrument upgrade and remote control
7. Can test turbine oil, insulating oil and diesel oil
8. Automatically save and print experimental results
9. Can be independently tested for condensing, pour point, can also test at the same time, a machine dual purpose
Technical Parameters:
Cooling speed: 5min temperature difference≥40°C
Measurement range: room temperature ~ -65 °C
Repeatability: ≤1°C
Reproducibility: ≤2°C
Resolution: 0.1 °C
Maximum power: 500W
Power Supply: (170~264)VAC, 50/60Hz
Try oil: 30mL each time
Cooling water pressure requirement: ≥0.5kg/cm2
Cooling water flow requirement: ≥1.5L/min
Printing function: The instrument has a built-in miniature thermal printer, which can automatically and manually print test results
Storage function: 500 test records can be stored, according to the date of operation, print
Dimensions: 455 mm × 345 mm × 290 mm (length * width * height)
Weight: 17kg
Dear Customer,
We,Xi’an Yima Opto-electrical Technology Com.,Ltd. is an integrated economic entity of R&D,manufacturing and trading with over 20 years of history.
Our business scope covers various fields such as biochemical analysis,environmental protection,industrial testing,bioscience,medical apparatus and instruments,internet technology and some frontier science.
Through a long-time development,we own a national resources system of various professional talents,abundant supply for various components & parts and special materials,full producing &processing equipments,strong Technological standardization and a complete quality assurance system.
If you need OEM or ODM in manufacturing,scientific research,market development and or you want to build your own brand in your country,it’s our honor to cooperate with you.In this way,we have developed many products for our customers from the USA, Europe and South Africa and got good feedback on Alibaba.
We firmly believe that science and technology is no boundaries.
Our mission is to make every effort to contribute to all humanity.
Your earlier friendly enquire from us would be highly appreciated.Thanks in advance!
