DM1000 Psychomotor Vigilance Task PVT Test System

DM1000 Psychomotor vigilance task PVT Test System

Introduction:

DM1000 series PVT test system is based on Burnett's high accuracy gas phase PVT test system, which can realize automatic testing of temperature and pressure and automatic temperature control.

Features:

1. Automatic control and measurement of temperature and pressure;

2. The temperature control system fluctuation is less than ± 50 mK/15 min;

3. The temperature measurement uncertainty is less than ± 50 mK;

4. The pressure measurement uncertainty is less than ± 30 kPa;

5. The system can also be expanded, as long as it is equipped with other thermal properties testing devices, can achieve the corresponding thermal properties test.

Product performance

6. Automatic temperature control: PVT Measurement test software can be used to set the temperature and automatically control the temperature to the set value;

7. Automatic pressure control: PVT Measurement software is used to automatically control the pressure in the pressure measurement system;

8. Automatic pressure and temperature measurement: PVT Measurement test software is used to automatically record the temperature and pressure values of each state;

9. Automatically calculate the density: Using PVT Analisys software, enter a series of temperature and pressure values obtained from the experiment to automatically calculate the density value of the tested sample.

Technical Parameters

Measuring principle: Burnett method

Temperature range: -30~120°C

Temperature fluctuation: ±50 mK/15 min;

Temperature measurement uncertainty: less than ±50 mK

Pressure measurement range: 0~13.8 MPa

Pressure sensor accuracy: 0.1%

Uncertainty in pressure measurement: less than ±30 kPa
