YD-20 Intelligent Tablet Hardness Testing Instrument

YD-20 Intelligent Tablet hardness testing instrument

Introduction:

YD-20 Smart Tablet Hardness Ceremony A drug testing device for measuring tablet hardness and diameter. Widely used in pharmaceutical factories, drug testing institutes and related research institutes.

Features:

1. The use of microprocessors to control the operation interface, a high degree of intelligence, powerful, easy to use.

2. High-precision load sensor ensures measurement accuracy.

3. LCD display, Chinese or English interface is optional, display content is rich, easy to use.

4. Automatically measure, analyze, display, and print measurement data.

5. With real-time calendar clock function, the date of detection and calibration can be printed in the test report.

6. With fault self-diagnosis function, it will automatically prompt some abnormal phenomena in the test.

7. The parameter settings are automatically saved until they are reset.

8. With calibration function, display and print calibration results.

Technical indicators

Measuring range:

Hardness 1~200N

          Resolution 0.1N

          Accuracy ±0.03Kg

          Diameter 2.0~30.0mm

          Accuracy ±0.01mm

Unit of measure: Hardness N/Kg/Sc (optional)

          Diameter mm/inch (optional)

Measurement method: manual monolithic/automatic continuous (maximum 160 pieces for measurement) / optional

Display: LCD display

      4 rows × 8 columns of Chinese characters or 8 rows × 16 columns of English/optional
