MDS -7 Automatic Frequency Conversion Controlling Temperature Pressure Microwave Extraction Apparatus

MDS - 7 automatic frequency conversion controlling temperature pressure microwave extraction apparatus
 Instruments:
 MDS - 7 type automatic frequency conversion temperature pressure double charged with microwave digestion/extraction device can accurately measure the temperature of the digestion tank, overtemperature automatically cut off the microwave, active defense super Wen Chao pressure accident, etc
 Digestion tank using acid (hydrochloric acid, nitric acid and aqua regia and hydrogen fluoride acid), alkali imports of polytetrafluoroethylene (PTFE), optional PTFE material imported, and deserve to wait for a variety of specifications and PEEK material outside the tank capacity (70 ml, 100 ml, etc.), good chemical stability, imports of PTFE material tank, the highest resistance to temperature 250 ℃, imports of TFM material tank, the highest temperature is 300 ℃
 With "overpressure automatic discharge gas pressure relief" and "explosion-proof membrane" double safety protection of FR series digestion tank (national patent no. : ZL 03249543.9)
Overheating protection: when the chassis or external tank overheating, instruments and automatic alarm and microwave radiation
Forced to suspend: once appear, security issues, but forced to suspend operation by way of "remote wireless remote control (optional)
Double-buffering explosion-proof door structure, peripherals such as high strength PC board cover a variety of security measures to ensure the safe operation of the equipment
Scope of application: FR - 30 digestion tank is suitable for the high organic matter content of food, environmental protection, such as complex samples, the resolution of high pressure to ensure high quality performance effect.FR - 50, 70, 100 digestion tank is suitable for food, plants, seeds, blood, and biological tissue, hair, soil, paper, plastic, glass, quartz and environmental samples and ceramics, oxide, oil, asphalt and other difficult to dissolve the sample.
Technical parameters:
1, the microwave power 1000 w, frequency: 1000 MHZ
2, USES the platinum resistance temperature control system, real-time display and control the temperature of the digestion tank, the temperature control range: 0-300 ℃, the monitoring precision of 0.1 ℃
4, non-contact inductive FM pressure measurement and control or the contact way of the ideal gas tank pressure is optional, real-time display and control the pressure of reaction tank, the control range: 0 to 10 MPa (1500 psi), precision is 0.01 MPa
3, can realize microwave high pressure digestion, microwave extraction, microwave COD digestion, amino acids and other digestion mode, support the EPA and ASTM standards
4, 1-6 samples of each batch processing at the same time, adopting planar microwave heating technology, multiple samples at the same time resolution uniformity is better

Main features:
The first domestic microwave heating technology into the tablet sample digestion, many samples at the same time resolution uniformity is better
Domestic pioneered in PFA spray furnace cavity, corrosion resistance, resistance to high temperature
Dropdown sliding door professional institutions, the impact of the effective protection for pressure relief
"" big furnace chamber design, furnace thick solid, high pressure work safer, with seven batch sample
Liquid crystal display panels, intelligent programming, can store a variety of sample treatment scheme, support the EPA standard method
Double CPU monitoring, intelligent PID automatic frequency conversion control, ensure the accuracy of sample digestion time and temperature
Multiple main passive safety protection measures: intelligent security alarm device, safety relief hole, safety explosion-proof membrane
 Choose the MDS - 7 type automatic frequency conversion controlling temperature pressure microwave digestion/extraction apparatus four reasons:
Science: 1. The analysis results of closed high-pressure digestion element to avoid the heat loss, ensure the AA, ICP, icp-ms for element analysis results are accurate and reliable;
2. The standard method of authority: you can refer to the EPA, AOAC, ASTM standard methods, such as running;
3. The convenient, quick, efficient: food, grease, soil and ore sample digested 15 to 30 minutes. Reagent dosage of only 5-10 ml, low blank and environmental protection
4. Advanced safety design concept: multiple main passive safety measures, to ensure safety;
