DW360 Portable Full -Digital Ultrasound Scanner

 DW360 Portable Full -Digital Ultrasound Scanner

Introduction

This equipment is convex linear ultrasound scanning diagnostic system with high resolution. It applies micro-computer control and digital scan converter (DSC), digital beam-forming(DBF),real time dynamic aperture (RDA),real time dynamic receiving apodization, real time dynamic receiving focusing(DRF),digital frequency scan (DFS),8 segments digital TGC, guide cannula puncture, frame correlation technologies to endue its image with clarity, stability and high resolution.

Features

For real-time picture uploading to PC2 USB ports;

2- probe connectors;

Monitor: imported 12 " LCD;

Probe elements : 96;

 Power Supply: AV220V±22V, 50MHz±1MHz;

Standard configuration: Main unit-3.5MHz Convex Probe

All accessories

 Optional:6.5MHz Trans-vaginal 7.5 MHz Linear ProbeVideo printer

 Technical Parameter:

Scanning mode: Convex/Linear/Micro-convex
Display modes: B,B+B,B+M,M
Scanning depth: 244 mm
Gray scales: 256
Cine-loop: 256 frames
Image permanent storage: 20 frames
Image magnification: 16 kinds

Image conversion: up/down, left/right, black/white
Zoom: 2 times both in real-time and frozen
Frame correlation: Three levels to adjust (B,B+B mode)
Electronic focuses: 2-sector dynamic
Depth scroll up in B and B+B modes
Resolution Lateral:≤2mm, axial≤1mm
Body marks: 30

Measurement: Distance, circumference ,area, heart rate, EDD
Note : date , name , gender, age , hospital , doctor,annotation
Pseudo-colors :8

Video output: PAL-D , Noninterlaced , SVGA
Monitor: 12" LED
Power Supply: 220V+_22 V, 50Hz

Standard configuration:

3.5MHz Multi-freq Convex Probe

12" LED Monitor

Options:

1). 7.5 MHz Multi-freq Linear Probe
2). 6.5 Multi-freq MHz Convex Probe
3). 7.5 MHz Multi-freq Rectal Linear Probe
