ZR-3061 Handheld Smoke Flow Rate Detector

Introduction:

The ZR-3061 hand-held flue gas flow rate detector is a portable instrument widely used in the determination of gas flow rate, gas flow rate, gas dynamic pressure, static pressure and temperature in boilers, kiln and various exhaust ducts.

Features:

1. Hand-held measuring instrument, light and portable, easy to operate.

2. Imported high-precision micro differential pressure sensor with high precision and small temperature drift.

3, LCD display, Chinese menu operation.

4, built-in lithium ion rechargeable battery, can be used continuously for more than 24 hours.

5. The parameters such as the average flow rate of the gas, the average pressure, and the flow rate of the flue gas can be automatically calculated.

6, with automatic zero correction, software calibration function to ensure measurement accuracy.

7, can save 200 sets of measurement data, not lost after shutdown.

Technical Parameters:

Pneumatic pressure

Parameter range: (0 ~ 2000) Pa

Resolution: 1 Pa

Accuracy: ≤±2%

Smoke static pressure

Parameter range: (-30 ~ 30) kPa

Resolution: 0.01kPa

Accuracy: ≤±2%

Flue gas temperature

Parameter range: (0 ~ 500) °C

Resolution: 1 ° C

Accuracy: ≤±3°C

Flue gas flow rate

Parameter range: (0~50) m/s

Accuracy: ≤±5%

Ambient temperature: (-20 ~ 50) °C

Ambient humidity: (10 ~ 95)% RH

Ambient atmospheric pressure: (60 ~ 130) kPa

Continuous working time: >24h

Dimensions W × D × H: (85 × 55 × 135) mm

Machine weight: about 0.5kg

Machine power consumption: ≤0.5W
