Gas Flow meter calibrator with temperature and pressure compensation ZR-5400
Brief intrduction
ZR -5400 roots gas flowmeter is used to calibrate small and medium flow rate meter and also suitable for other flow calibration/verification widely used in metrological verification environment monitoring, labor insurance research institutes
Featrue
Wide range, high precision
Real-time measuring temperature environment barometric pressure of environment
Automatic conversion of flow rate under standard condition
Dot-matrix LCD screen
AC/DC Compatible, built-in high-energy lithium battery
Records up to 200 groups
USB interface is available, support to output data into USB flash disk
Has print interface, external printer is optional
Technical parameter
Main indicators | Range | Resolution | Maximum Permissible Errors |
Flow range | (10~260)L/min | 0.1L/min | Better than±1.0% |
Environmental atmospheric pressure | (60~130)kpa | 0.01kpa | Better than±0.5kpa |
Working temperature | (-20~50)℃ |
|
|
The battery working time | >10h |
|
|
The battery adapter | Input AC100~240V 50/60Hz,Output DC5V 2A |
|
|
Size of the host | (L*W*H 300*230*260 mm) |
|
|
Weight | About 7kg |
|
|
Power consumption | ≤5w |
|
