ES20B-N2O Portable N2O analyzer anaesthetic gases detector
- 500 Set / Sets per Month
- shenzhen
- T/T Credit Card
- ES10B11-N2O online N2O monitor warner Nitrous oxide detector
- HT-9600 particle counter PM0.3 PM1.0 PM2.5 PM10 monitor air dust analyzer
- ZR-3260 portable Automatic flue gas dust analyzer handheld chimney stack gas monitor
- GXH-1050E NDIR intelligent online process gas analyzer infrared spectroscopic gas monitor gas composition detector
- CEA--800 intelligent infrared carbon dioxide detector NDIR CO2 monitor
- SDL607 laser indoor air quality monitor pm2.5 pm10 Factory supply
Product Details
Brand Name: | WUYANJIE-W | Place of Origin: | Shaanxi, China | Model Number: | ES20B-N2O |
Product Description
Brief introduction
ES20B is a high-end portable gas detector, using full metal jacket, using the new imported sensor and 32-bit low-power processor; using four layer wiring circuit, the weak signal and anti-jamming stronger; independent imported high-precision ad chip (some manufacturers for the cost savings use 2 layer circuit board and CPU built-in functions of the AD) with unique signal processing algorithms, accuracy is higher and more stable; 2.5 inch dot matrix display interface, intuitive readings and generous; first-class technology design, bringing the rock solid quality. Can be applied to all kinds of dangerous industrial places, products are widely used in metallurgy, petroleum, petrochemical, municipal, chemical, bio pharmaceutical, home environmental protection, school laboratory, automobile exhaust and other fields.
Features
All metal shell, ergonomic design, feel full, highlight the high-end quality;
Using independent precision AD chip, 4 layers of circuit board design, weak signal and anti-interference ability;
2.5 inch dot matrix display interface, large font interface reading beautiful, menu design scientific and reasonable;
Imported high performance sensor, high measuring precision, good repeatability, long service life;
Built in high performance suction pump, stable flow rate, can switch control;
Temperature and humidity display, and powerful data storage function (optional);
Mg/m3, PPM, VOL, LEL, PPB a variety of units can be selected;
Using embedded 32 bit ultra low power processor, with unique signal processing algorithm, fast response, stable;
Scientific and reasonable sound and light alarm design, the curve is symmetrical, detection of excessive warning, timely warning, to protect the personal safety.
First class industrial design, the fuselage uses the military quality high strength aluminum profile, wear resistance and corrosion resistance, suitable for complex and harsh industrial environment;
Packing list
Standard configuration:Host,USB Adapter,Charge cable,User manual
Optional component:Extension tube,sampling controller,system software
Technical parameters
Item | Description |
Detecting gas: | N2O |
Working principle: | Electrochemical |
Sampling method: | Pump suction/dispersive |
Measure range: | 0-10ppm,50ppm,100ppm,200ppm,500ppm,1000ppm,2000ppm,5000ppm (Optional, other range can be customized) |
Resolution: | 0.01ppm(0-100ppm) |
Accuracy: | ±3%FS |
Repeatability: | <3% |
Respond time: | T90 ≤30 sec |
Alarm method: | Sound and light alarm, double color LED lamp, sound or 75 db @ 25 cm |
Operation method: | Key operation(Life time of keys:2000000 times) |
Material of host: | Full metal jacket, strong wear resistant corrosion, feel is good |
Working temperature: | -30℃~+70℃(Conventional gas),-20℃~+50℃(poisonous gas) |
Working humidity: | 10%RH ~95%RH,No condensation |
Working pressure: | 86kPa~106kPa |
Battery: | Built-in high-performance lithium-ion batteries, import core: nominal voltage 3.7 VDC, 2500 mah |
Charger: | Travel charger with USB interface, USB power supply DC5V, charging temperature range: 0 ℃ to 40 ℃ |
Charging time: | ≤6 hours, total charged time 12 hours |
Continuous working time: | ≥12 hours |
Dimension: | 130×63×34mm(L×W×H) |
Weight | About 0.46Kg |
Protection grade: | IP66 |
Execution standard: | GB15322.1-2003,GB3836.1-2010,GB3836.2-2010,GB3836.4-2010 |
Quality assurance: | One year warranty, the warranty period free maintenance, sensitive components such as sensors, according to the standard of sensor manufacturers. |
