EA061 Calibration Gas Dynamic gas calibration instrument dynamic gas regulator calibrator

Brief introduction

Dynamic gas calibration instrument is a microprocessor based calibration instrument used to calibrate the precision gas analyzer. Using high precision mass flow controller, controlling the flow of standard concentration compressed gas and dilution gas, the zero calibration and calibration of the gas analyzer can be carried out.

XHCAL2000B can be equipped with an optional UV ozone generator that provides accurate and reliable concentrations of ozone gas; and is equipped with an internal gas phase titration (GPT) chamber, a mixture of NO standard gases and ozone, producing standard concentrations of NO2 gas. In order to improve the accuracy of the ozone generator and GPT, an optional ozone spectrometer can be internally configured to accurately measure the concentration of ozone produced. In order to ensure the highest accuracy of the NO2 output, the configuration of the ozone spectrometer calibration instrument in the pre GPT can be pre accurate measurement of ozone concentration.

Features

Generate accurate SO2, H2S, NO, NO2, CO, O3 and other calibration gases;

12 independent timers support process editing and execution;

Linearization of mass flow controller (MFC) software;

4 way calibration gas port (can be configured with single or multiple gas mixture);

The internal flow of the instrument is controlled by the mass flow controller, and the accuracy of the flow control is 1%;

Gas phase titration (GPT);

Optional ozone generator and ozone photometry, allowing the use of primary or transfer standard;

The instrument has the function of diagnosis, which can easily and quickly find out the fault location of the instrument;

Instrument can be in the flow, pressure and other parameters are not normal when the automatic alarm;

Various communication methods, arbitrary choice: can choose RS232, 485 serial port output, voltage output (0~10V), current output (4mA-20mA).

Technical parameter

Dilution system: flow measurement accuracy of 1% full scale

Flow control repeatability: 0.2% full scale

Linearity of flow measurement: 0.5% full scale

Dilute air flow range: (0-10) L/min

Optional range: (0-20) L/min

Standard gas flow range: (0-50) ml/min

Optional range: (0-100) ml/min

Dilution ratio: 50:1~2000:1

Dilute gas input pressure: 175kPa~225kPa

Calibration gas inlet: 4 (configuration)

Dilution gas inlet: 1

Ozone generator module: maximum output 10ppm

Minimum output: 50ppb

Accuracy: + 2%FS

UV photometric options: range: (0-500) ppb to (0-10) ppm (optional)

Accuracy: + 1% read value

Minimum detection limit: 1.0ppb
