Help CenterEA085 Smoke Sampling Tube Type of Low Concentration Sample Gun Probe
Related Products
-
EA087 Type Smoke Sampling Tube of Heavy MetalsUS$ 2,800 - 3,200MOQ: 1 Set -
ES10B-TVOC TVOC VOC PID Monitor Detector AnalyzerUS$ 2,000 - 2,100MOQ: 1 Set
-
YM-B5 Laser Scattering Particulate Matters Detector Intelligent PM2.5 MonitorUS$ 40 - 55MOQ: 1 Unit
-
EA057 Ultraviolet Photometric Method O3 Ozone Analyzer MonitorUS$ 8,900 - 11,000MOQ: 1 Set
-
EA056 Gas Filter Correlation Spectroscopy CO Monitor AutomaticallyUS$ 11,000 - 12,500MOQ: 1 Unit
Brief introduction
MH3090 low concentration of smoke sampling tube is suitable for the stationary sources in the exhaust gas concentration determination of particulate matter less than 50 mg/m3.Sampling tube by contains membrane sampling head and sampling head fixed device to replace the filter cartridge and the cartridge sampling tube, a membrane sampling head back end with heating function, keep the membrane filter work under the temperature of the set, can adapt to the working condition of high humidity and low dust, etc.One-piece sampling head, can filter membrane, bending and membrane bracket before as a whole is weighed, minimize the chances of the membrane filter quality and particle loss.
Features
Apply to capture stationary sources in the exhaust gas concentration is lower than 50 mg/m3 particulate matter;
2. Compact structure, and is suitable for the standardGB/T16157Specified in the80mmThe hole diameter measurement;
3. The24VDc power supply heating, the heating temperature can be set and automatic adjustment;
4. Sampling mouth and bend USES titanium alloy materials, stable performance, corrosion resistance, the low loss;
5. The diameter 47mmCollection of membrane filter particles;
6. The whole weighing way, one-piece overall weighing, sampling mouth;
7. Efficient membrane heating equipment, in view of the low humidity condition of dust;
8. The filter membrane, membrane filter upstream components and weighing filter membrane bracket as a whole;
Technical Parameter
The main parameters |
ginseng The number van wai |
|
type No. |
MH3090type |
MH3090Ttype |
material mass |
Stainless steel |
Titanium alloy |
heavy The amount |
about3.25kg |
about2.15kg |
The minimum detection limit |
1mg/mafter |
|
Pitot tube coefficient |
0.84Plus or minus0.01 |
|
A membrane diameter |
47mm |
|
The heating temperature |
(80-80.) ℃ |
|
Sampling tube length |
standard1.5m,Can be customized |
|
Hole diameter measurement requirements |
Acuity 80mm |
|
Working voltage |
DC24V |
|
Heating power |
100W |
|
