PCS-A Multifunctional water quality detecting instrument

Introduction :

PCS-A Multifunctional water quality detecting instrument use for detection of water quality turbidity, chroma, ammonia nitrogen and nitrate nitrogen, nitrite nitrogen, chlorine (free residual chlorine, total chlorine (CL), chlorine

dioxide, iron, manganese, urea, chloride, sulfate, formaldehyde, sulfide, cyanide, phosphates, fluorides,

hexavalent chromium, consumption of oxygen cod, total hardness, lead, cadmium, ozone, arsenic, copper,

 calcium, phosphorus, total dissolved solids. Oxygen, odor and taste, naked eye visible matter, PH value, total dissolved solids

(33 items)

Features :

Portable design, portable, and can be no power access to the site for a long time detection.

All solid state optical system to ensure excellent optical performance;

The computer workstation has 14 inch large screen display, keyboard and mouse operation, operation is more rapid and convenient.

The use of standard computer workstation communication interface, support a variety of external memory;

Support video and audio playback function, facilitate the teaching and training; software interface directly

 display the help files, easy to operate.

Standard high protection performance of the instrument box, waterproof, anti shock, vibration, humidity etc.

Technical parameters:

Optical system: convergence type tungsten lamp light source, concave flat field holographic grating

Measurement methods: food quality analysis, spectral scanning, quantitative measurement, time scanning;

Detector: 3648 pixels CCD

 Wavelength range: 400nm ~ 800nm continuous spectrum;

Spectral bandwidth:1nm;

Wavelength indication error:±1.0nm;

Wavelength repeatability:≤0.1nm;

 Baseline flatness:±0.005Abs;

Noise :≤0.5%τ;

Drift :≤0.5%τ/30min;

stray light: ±1.0 %τ(420nm);

Transmission ratio error:±1.0%τ;

Transmission specific gravity:≤±0.5 %τ;

Size :240mm×220mm×85mm;

Weight  :1.5kg
