Introduction
GZZ11 digital radiosonde integrated application of the advanced and mature technology of GTS1 radiosonde and GZZ2-07-1 radiosonde. Temperature, pressure and humidity sensor accuracy can meet the requirements for atmospheric sounding, is a transformation has been optimized and high-tech products.
In 2003, GZZ11 digital radiosonde atmospheric detection through comprehensive testing base CMA full performance test, and the company with the Vaisala radiosonde GPS performance comparison tests were made and the use of tests. The results show that the products meet the quality requirements of technical conditions, has high accuracy, transmission speed, sampling speed is high, strong anti-interference performance, scalable conversion circuit, easy to use and so on.
GZZ11 figures solve the problem that the LLX01B high-altitude radiosonde meteorological radar should be supporting by Digital radiosonde. Replaced the technology behind the 701-GZZ2 machine code radiosonde system.
Main Specifications
Measuring performance:
| measuring range | |
| temperature: | +50°C~-90°C |
| Humidity: | 0%RH~100%RH |
| Pressure: | 1060hPa~5hPa |
| Measurement range | and accuracy (standard deviation): |
| Temperature: | +40 °C ~ -80 °C | Accuracy: | ± 0.2 °C |
| Humidity: | 15% RH ~ 95% RH | Accuracy: |
-25 °C more than ± 5% RH; -25 °C following ± 10% RH |
| Pressure: | 1050~5 hPa | Accuracy: |
500hPa following ±2hPa 500hPa more than ±1hPa |
| Electrical properties | |
| carrier center frequency (f0): | 397 ± 2MHz |
| Carrier Frequency Stability: | ± 5MHz |
| f0 launch peak power: | 400mW |
| answer pulse width | 0.8μS ~ 3.5μS |
| modulation frequency: | 32.7 ± 0.5kHz |
| transfer rate: | 1200 Baud |
| Sampling period: | 1.5s |
| Power supply: | DC 12V ~ 15V, working time 100min |
| Weight: | 400g (including batteries) |
:
