SV-4Q Automobile Exhaust Emission Gas Analyzer for Petrol Gasoline Car Car Automobile Exhaust Gas

SV-4Q Automobile exhaust gas analyzer for petrol gasoline car

Brief introduction

SV-4Q automobile exhaust gas analyzer (hereinafter referred to as the analyzer) may, in accordance with non-light-disguising infrared absorption method, via micro-computer analysis, directly measure the thickness of HC, CO and CO₂ in the exhaust gas of vehicles and inspect the density of O₂ via Electrochemical sensor so as to calculate excess air coefficient λ. The analyzer introduces advanced foreign technology. It is composed of complete imported machinery cores, boasts the advantages of accuracy measurement, high endurance and speed. As an Intelligent Equipment, it is equipped with Microprocessor, LCD and Chinese language interface. Besides, it also has optional equipments such as Induction Tachometer, temperature sensor, inner Micro Printer for customers to purchase. The newly-added Storage function can detect Engine’s speed and Lubricant’s Temperature while measuring tail gas, then store and print the results

Technical parameters

1.Measurement range

 CO    0~10.0   10^-2(%)      CO₂  0~20.0  10^-2(%)       HC    0~10000 10^-6(ppm)

 O₂     0~25.0   10^-2(%)       oil temperature    18-150ºC rotate     speed    100-20000rpm

2. Repeatability ≤±2%

3.zero floating

CO     ±0.06  10^-2(%)/1h       CO₂      ±0.5   10^-2(%)/1h

HC     ±30   10^-6(ppm)/1h        O₂        ±0.5   10^-2(%)/1h

4.span floating      Not exceed the allowed value for indication error(1 hour)

5.indication error

CO   ±5% (relative error,0-10%)

CO₂ ±5% (relative error,0-20%)

HC   ±5%(relative error ,0-4000ppm)±10%  (relative error,4001-10000ppm),

O₂   ±5%   (relative error,0-25%)

oil temperature     ±2°C  (absolute error)

Rotate speed        ±1.0%    (relative error)

6.Environmental condition

temperature    0°C~40°C

 humidity   ≤95%

Air pressure    60~105kPa

power   AC  220V±10%;50Hz

7.preheat time   5min
