Home > Products > Environment monitoring instruments > XLZ-1090 GXH Infrared Carbon Monoxide Analyzer
XLZ-1090 GXH Infrared Carbon Monoxide Analyzer
- shenzhen
- T/T Credit Card
You May Like
Product Details
| Brand Name | Xilinzi | Place of Origin | Shaanxi, China | |
| Model Number | XLZ-1090GXH |
Product Description
XLZ-1090 GXH Infrared carbon monoxide analyzer
Introduction
1. For the monitoring of atmospheric pollutants and emissions
2. Used in petroleum, chemical , power plants and other industrial process control
3. For the field of agriculture, health and scientific research
4. Laboratory variety of determination of the gas content of the combustion test
5. Air monitoring for public places
Feature
Standard 19 chassis can be installed in the equipment
large-screen LCD display , full Chinese menu operation , and operating tips , simple operation , high efficiency
The all-digital processing , more accurate and reliable
Standard RS232 digital communication functions , and can be directly connected to the computer or DCS
Output synchronization (0/2/4-20) mA isolated , and ( 0/0.5/1-5 ) V signal is optional , the default is (4-20) mA and (1-5) V , current output load ≤ 400Ω, voltage output load ≥ 250Ω
Completely isolated calibration, fault , alarm, the output signal
Technical Data
Range : minimum range of 0 ~ 50ppm; maximum range of 0 to 100% (based on the need to determine )
Repeatability : ≤ 1%
Resolution: constant : ≤ 0.01% v / v , trace : 1ppm
Zero drift ≤ ± 1% F.S
Span drift : ≤ ± 1% F.S
Linearity error : ≤ ± 1% F.S
The response time of the instrument : T90 ≤ 15s
Measured gas flow rate : 0.5 ~ 3L/min
Ambient temperature : 0 to 40 ° C ;
relative humidity : ≤ 90%
Power supply : 220V ± 10 % ; 50 ± 0.5Hz 150W
