Turbidity probe and turbidity transmitter is the key part of this instrument, and the integrated circuit board, which is filled with photoelectric converter and integrated circuit board. Turbidity meter in the factory has set a good debugging, within a password, users do not need to set.
Calibration potentiometer, used to adjust the accuracy of the instrument. In the verification of the competent department of measurement the instrument, or the user in the instrument used for a long period of time, for some reason cause deviation confirm the measured values are not on time, with zero water and 10NTU standard turbidity solution, by the inspection personnel or the users themselves to the instrument accuracy calibration. Generally do not need to adjust.
Zero adjustment knob used to adjust the zero position.
Technical Parameters
1,Accuracy | <FS±2% |
2,Repeatability | <FS±1% |
3,Resolution | 1NTU( measure range:0-1000NTU) |
4,Drift per hour | <0.1NTU |
5,Working Temp | 4—50℃ |
6,Relative humidity | <70%RH |
7,Power supply | 200~240V 50HZ |
8,Power consumption | <25W |
9,Output signal(standard) | 4-20mA |
10,Dimension(transmitter) | 269×190×100mm3 |
11,Weight | 3kg |
12,alarm | upper and lower limit alarm |
