BT100-1E Dispensing peristaltic pump
SpecificaSpeed: 0.1-100 rpm, reversible
Speed resolution: 0.1 rpm
Dispensing volume: 0.01 mL to 9.99 L
Copy number: 0 to 9999, 0 means unlimited cycle.
Speed control: Rotary encoded switch
Pause time : 0.1 s to 99.9 min
Flow rates calibrating time: 0.5-30 min
External control input interface: start/stop control, direction control, flow rates control(0 - 5V , 0 - 10V , 4 - 20 mA , 0 - 10KHz optional )
Output interface: start/stop, direction output and 0 - 10 KHz frequency output (corresponding to 0.1 to 100.0 rpm) with insulating function
Communication: RS485
Power: AC 100-240 V ± 10%, 50/60 Hz
Power consumption: < 40W
Operating condition: Temperature 0 to 40°C, Relative humidity < 80%
Dimensions (L × W × H): 285 × 207 × 180 (mm)
Drive Weight: 3.8 kg
IP rating: IP 31
Functions and Features
Applicable pump heads: YZ1515X, YZ2515X, YZII15, YZII25 andDG-1, DG-2, DG-4
Micro flow rates transferring: The smallest flow rate can reach 0.2 μL/min
Back suction function: In dispensing mode, the pump runs reversely after stopping to prevent the liquid from dripping
| Operating mode: Membrane keypad and rotary encoded switch Speed control: The speed can be adjusted manually or automatically through external control interface Display: LCD displays current running status Prime key: For fast filling and emptying Memory function: Storing the running parameters automatically Calibration function: The flow rates and the dispensing volume can be calibrated to increase the accuracy Communication function: Realize computer control through RS485 communication interface |
