HG-200 Large Flow Suspended Particle Online Monitoring System Large Volume Air Samplers

HG-200 large flow suspended particle online monitoring system

Introduction:

The suspended particle online monitoring system records the presence of airborne particles in critical areas of the production line. It can automatically and continuously monitor and record the particle size and quantity distribution of suspended particles in the monitored ambient air, and generate reports. When the state of the dust particles in the monitoring environment exceeds the warning line and the correction line, the system can automatically activate the sound and light alarm and notify the relevant personnel to process, thus helping to ensure that the particle conditions in the monitored critical environment are in a normal state to ensure production. Going smoothly.

Features:

1. 28.3 liters / minute sample size

2. Real-time reflection of dynamic changes in the environment

3. The system uses double sampling pumps to alternately use, so that the vacuum degree in the vacuum tank is stabilized at the set value, prolonging the service life of the vacuum pump.

4. Each channel in the system has a flow sensor to monitor the sampling flow, and convert the detected actual sampling flow into 1m3 data.

5. The system uses a pneumatic box to subdivide the total vacuum tube into sampling tubes for each sampling point, which is convenient for debugging, overhaul and maintenance.

6. The system expansion is very convenient, both the sampling point can be arbitrarily increased, and the sampling of floating bacteria, wind speed, differential pressure, temperature and humidity, etc. can be integrated.

8. The system can be connected to the Internet to view system status in real time around the world.

9. The software system is fully compliant with computerized verification requirements

Technical Parameters:

Measuring particles: 0.5, 5.0 μm

Sampling flow rate: 28.3L/min (1.0CFM)

LED status display: display the working status of the suspended particle transmitter, the green light is on, the prompt is normal, and the non-lighting is not working.

Laser wavelength: 650nm

Material: stainless steel housing SUS 316

Mode of operation: touch screen or computer operating software

Signal output: RS232/RS485 or 4-20mA

Power supply: 7.4-12VDC

Laser life: 60,000 hours

Installation position: The transmitter is installed on the equipment or wall, the constant velocity sampling tube is installed at the sampling point, and is installed separately from the constant velocity sampling tube.
