BTS-5V10mA Battery Testing Equipment
- Shenzhen
- T/T Credit Card
You May Like
-
JK9830 Kjeldahl Semi-Auto Analyzer
-
K1003 Photoelectric Electrochemical Cell
-
YIMA-IC Automatic Colony Counter Colony Counter
-
CIC-200 Ion Chromatograph Introduction
-
NM-G1 Nuclear Magnetic Resonance (NMR) Imaging Small Animals
-
MicroMR-G MesoMR Pore Structure Analysis and Nuclear Magnetic Resonance (NMR) Imaging System
Product Details
| Brand Name | KEWEI-Y | Model Number | BTS-5V10mA | |
| Power | Electronic |
Product Description
BTS-5V10mA Battery Testing Equipment
Introduction
BTS 4000 entered into market in the year of 2008.
Now it is one of the most successful and most popular battery testing system in China.
Thousands of battery manufacturers, battery research institutes and laboratories use it as their primary testing partner for their various testing activities.
Technical Parameter
Project index | Parameter index | |
Input Power | AC 220V ±10% / 50Hz | |
resolution | AD:16bit;DA:16bit | |
Input Resistance | ≥1MΩ | |
Input Power | 709mW | |
Channel Features | Constant Current Source and Constant Voltage Source with Independent pairs of Closed-loop Structure | |
Channel Control Mode | Independent Control | |
Voltage | Per Channel Voltage Range | Charge:25mV~5V;Discharge:25mV~5V |
Discharge Min Voltage | 2.5V | |
Accuracy | ± 0.05% of FS | |
Stability | ± 0.05% of FS | |
Current | Per Channel Current Range | 0.05mA~10mA |
Accuracy | ± 0.1% of FS | |
Constant stop current | 0.02mA | |
Stability | ± 0.05% of FS | |
Power | Per Channel Output Power | 50mW |
Stability | ± 0.1% of FS | |
Time | Current Response Time | 20ms (0-Full Range) |
Step Time Range | ≤(365*24 )hour/step, Time Form Support 00:00:00(h,min:s,ms) | |
Data Recording | Record Condition | Lower sampling time:100ms |
Lower sampling Voltage:5mV | ||
Lower sampling Current:0.01mA | ||
Record Frequency | 10Hz | |
Charge | Charge Mode | Constant Current Charge,Constant Voltage Charge, Constant Current and Constant Voltage Charge,CPC |
