Introduction
GC1100P gas chromatograph is a high performance , small size, for volatile organic compounds in analytical instruments.
The instrument uses a high -sensitivity miniature Photoionization detector , EPC electronic flow control technology and fast column heating system, and with automation and control equipment for the design of special software , real-time , on-line for rapid analysis of volatile organic compounds . In addition to the conventional gas chromatography instrument of powerful , but also has a small , fast and suitable for field testing . Can be widely used in anti-terrorism, spills , contaminated areas in various fields confirmed that protection.
Features:
1 ) precise control :
The instrument uses advanced temperature control system , temperature control and high accuracy (better than ± 0.2 ℃), high reliability, strong anti-jamming capability ; the highest temperature control up to 300 ℃; oven temperature program up to 30 bands ; and has been temperature protection to ensure the safe operation of the instrument .
Pneumatic flow control system uses electronic modules , convenient and reliable installation. Flow control module, a flow range 0 ~ 300ml / min, accuracy ± 0.2 ml / min; pressure control module , a pressure range of 0 ~ 60psi, accuracy ± 0.1 psi.
2 ) easy to operate :
Equipment installation dedicated analysis software, the instrument automatically starts sampling , automatic acquisition and control temperature and flow , automated analysis and processing, and generate test reports.
Instrument not only locally via mouse and keyboard , but also for remote control operation via a network connection , as long as there is access to the Internet for computers, mobile phones , ipad , etc. can be manipulated .
3 ) comprehensive technology portfolio :
EPC control system for the first time and programmed temperature control technology in micro-gas chromatography instruments , the high degree of automation , control and high precision , fully completed GC instrument various operations.
Technical parameters:
UV light source : 10.6 eV
The maximum heating rate : 300 ℃ / min
Detection limit : 4 × 10-12 g / s
Qualitative Repeatability : RSD≤1%
Quantitative Repeatability : RSD≤3%
Column temperature control range: ambient temperature to 250 ℃
Temperature stability : ± 0.2 ℃
Working temperature : 0 ~ 40 ℃
|
