XH-800US intelligent ultrasonication cell disruption
Introduction
The instrument abandon the traditional ultrasonic cell disrupter power and probe split , power bulky defects , the use of integrated circuit control system, greatly reducing the volume of the instrument . The power of the probe , and operating system integration. Transducer probe with automatic lift, ultrasonic frequency automatic tracking , automatic temperature display.
Product Features
Instrument uses a single chip control technology and phase-locked loop frequency automatic tracking technology, through simple keyboard operation to set the data and control of the state . Power setting and temperature measurement circuit enables MCU ultrasonic transmitter power and over-temperature protection and alarm functions . And according to the viscosity of the reactants , the temperature difference , through automatic frequency tracking automatically to achieve the best sonic result . The instrument to achieve a portable machine functions. Probes for the import of titanium alloy material , durable, and are equipped with 8mm, 18mm horn . Temperature inside the box with PTFE coating processing technology, every speaker can effectively reduce the work during the noise , reduce the experimenter interference.
Technical parameters
1. Ultrasonic power: 0 ~ 1500 w continuous adjustable.
2. The ultrasonic frequency: 25 KHZ frequency automatic tracking, with automatic sweep frequency lock function.
3. High precision temperature sensor, the real-time monitoring system of temperature, temperature measuring range: 0 ~ 100 °C; Temperature measuring accuracy: 1 ‰
4. Work time: the biggest setup time is 100 hours, can be in this range any set work time.
5. The ultrasonic amplitude titanium alloy rod diameter: 8 mm, 18 mm is suitable for different diameter of the container.
6. Crushing capacity: 10 ml to 1000 ml
7. Working mode: ultrasonic pulse work arbitrary adjustable. With more than set temperature protection automatic ultrasonic work mode.
Dear customer,
We ,Xi’an Yima Opto-electrical Technology Com.,Ltd. is an integrated economic entity of R&D,manufacturing and trading with over 20 years of history .
Our business scope covers various fields such as biochemical analysis,environmental protection,industrial testing, bioscience,medical apparatus and instruments,internet technology and some frontier science.
Through a long-time development,we own a national resources system of various professional talents , abundant supply for various components &parts and special materials, full producing &processing equipments , strong Technological standardization and a complete quality assurance system.
If you need OEM or ODM in manufacturing ,scientific research , market development and or you want to build your own brand in your country, it’s our honor to cooperate with you.In this way ,we have developed many products for our customers from the USA, Europe and South Africa and got good feedback on Alibaba
|
We firmly believe that science and technology is no boundaries Our mission is to make every effort to contribute to all humanity. |
