EDX 100a X -ray fluorescence analyzer

EDX-100a X -ray fluorescence analyzer

Product description:

EDX100a is the latest RoHS developed for the detection of fluorescence analyzer, mainly detected in the production process and raw materials may contain lead , cadmium , mercury , hexavalent chromium , polybrominated diphenyl ethers , polybrominated biphenyls six hazardous substances in electrical and electronic products ( including: white appliances , such as refrigerators , washing machines, microwave ovens, air conditioners, vacuum cleaners, water heaters, etc. ; black appliances , such as audio, video products , DVD, CD, TV receivers , IT products, digital products , communications products ; electric tools, electric and electronic toys , medical electrical equipment , etc.) as a tool for environmental testing .

Instrument features:

High sensitivity
Automatic detection of qualitative analysis of lead , cadmium , mercury , hexavalent chromium , polybrominated diphenyl ethers , polybrominated biphenyls six hazardous substances.
Using imported SI-PIN detectors , rapid analysis .
Automatic lifting platform .
High accuracy, good stability , low failure rate .
Multi-layer shielding , radiation safety and reliability.

main technical indicators:
Energy dispersive X -ray fluorescence analysis
Analysis of the elements Si ~ U (Cd / Pb / Cr / Hg / Br precision type )
         Na ~ U ( optional : φ1.2mm/φ0.1mm switch mode type )
Detection limit of Cd / Pb / Hg / Br / Cr ≤ 5ppm
Sample shape 460 × 380mm ( height 150mm)
Sample: Solid Liquid Powder

Target Rh X -ray tube voltage  50KV

Tube current  1mA

X -ray irradiation diameter 1/3/5mm
Protection <0.1mR/Hr ( radiation below the computer screen )
Imported electric refrigeration UHRD detectors.
Built-in HD webcam
Qualitative analysis : Auto qualitative ( automatically go to background / automatic stripping overlapping peaks / automatic compensation escape peaks / automatic drift compensation spectra )
Software irradiation diameter : 1/3/5mm
Quantitative analysis: fundamental parameter method / standard method / 1:00 Correction
