Instrument features
1. computer recrimination , a computer can control N (N ≤253) chromatograph with a six -channel temperature control system ; four- time program system .
2. Chromatograph using advanced technology 10/100M Ethernet communication interface , can achieve
remote control of the instrument and remote data transmission processing and monitoring .
Can be connected to the unit heads and supervisors to facilitate the implementation of the
competent supervision.
3. Digital signal output ( built chromatography workstation ) , the signal cable directly to the output .
4. Can be equipped with three kinds of commonly used detector at the same time.
5. Large column box with automatic back door can be 8 -stage temperature programming ; near room temperature control function ( temperature above 5 °C).
6. The instrument can be configured sample packed column, capillary column sampler, gas sampler,
conversion,
thermal desorption devices, roof air sampler, thermal cracking device, automatic injector, etc.
7. fault self-diagnosis function, at any time according to fault location, and nature;
Overtemperature protection function
Technical parameters
1. Detector
|
Thermal conductivity detector |
Hydrogen flame detector |
Electron capture detector (ECD) |
Flame photometric detector (FPD) |
|||
TCD-1 |
TCD-1H |
MTCD |
FID |
|
|
|
|
sensitivity (detection limit) |
≥3000-10000mV.ml/mg(benzene) |
≤5.0×10-12g/s(N-hexadecane) |
1×10-13g/ml(γ-666) |
5×10-12g/s(P) |
||
Baseline noise |
≤0.01mv |
≤1×10-13A |
≤40 uV |
≤40 uV |
||
Baseline drift |
≤0.1mv/30min |
≤ 5×10-13A/30min |
≤100uv/30min |
≤100uv/30min |
||
Linear range |
105 |
107 |
104 |
104 |
||
|
Stabilization time |
≤1.5h |
≤1h |
≤2h |
≤1h |
||
2. Temperature Control
Temperature range: Oven volume : 280 × 280 × 180mm
Temperature range : room temperature above 5 °C -400 °C
Temperature Accuracy : ± 0.5%
Display accuracy : 0.1 °C
Program order : 8 Order
Programming rate :0-39 °C / min ( adjustable increments of 0.1 °C / min)
Temperature program Repeatability : ≤ 1%
3. the host size : 650 × 480 × 500mm
4 .Instrument Weight : 56kg
5. Power: 2000W
You see on our website products quotation, just a market reference price. We can according to customer specific requirements to give the actual price.
