Features of yoga mat vibrating knife cutting machines
1. Cutting by knife not laser, no air pollution , no burnt edge, cutting speed is 5-8 times faster than laser cutting machine.
2. Imported square linear guide and Japanese servo motor ensure high precison and fast cutting speed.
3. The application of an Ethernet port makes the cutting plotters fast and convenient.
4. This cutting machine was designed easy to install, set-up and operate.
Application and cutting samples
It can cut
Official website:/
Specification
Technical parameters / model |
AOL-1625-ZS6 |
AOL-1825-ZS8 |
AOL-2125-ZS10 |
Accept unconventional model customization |
||
Effective working area |
1600x2500mm |
1800x2500mm |
2100X2500 |
|||
Multi-head optional |
Double head optional efficiency doubled, double gantry optional, double head mutual shift optional, length can be customized |
|||||
Multi-function tool |
Vibrating knife full cutting, high power active round knife, punching tool, pneumatic knife, multi-layer knife |
|||||
safety devices |
Safety devices use infrared sensing, safe and reliable |
|||||
Cutting speed |
200-2000mm/s |
|||||
Cutting thickness |
≤50mm Other thicknesses can be customized according to the material |
|||||
Material fixing method |
Vacuum partition adsorption |
|||||
Transmission port |
Network port |
|||||
Transmission system |
Yaskawa servo motor, linear linear guide, timing belt, lead screw |
|||||
rated power |
11kw |
|||||
Rated voltage |
380V±10%/220V±10% Optional |
|||||
Control System |
Chinese and English LCD touch screen |
|||||
Operating environment |
Operating environment Temperature 0-40°C Humidity 20%-80%RH |
|||||
Software |
Automatic nesting software, template entry software（Optional） |
|||||
Support file format |
AI、PLT、DXF、CDRetc |
|||||
Overall size |
3570x2290x1165mm |
3570x2500x1165mm |
3570x25800x1165mm |
|||
Machine Advantages
Machine Service
About AOL
AOL is one of the famous professional yoga mat vibrating knife cutting machines manufacturers and suppliers in China，yoga mat vibrating knife cutting machines price is right.If you need it, please contact us.
Jinan AOL CNC Equipment Co., Ltd. is a professional manufacturer of intelligent cutting equipment. The company specializes in providing cutting and engraving integrated solutions for the non-metal industry. In the environment of advocating environmental cutting, the company replaced the laser with a smart blade and developed a vibrating knife, a drag knife, a round knife and a half cutter.
Various tools such as beveling cutters, pressure rollers, punching knives, milling cutters, etc., combined and equipped, coupled with the assistance of large cameras and projectors, have basically met the cutting and engraving needs of all flexible industries.
The company's main products are advertising material cutting machine, car interior cutting machine, clothing bag shoe and hat cutting machine, packaging carton cutting machine, composite material cutting machine, furniture home textile cutting machine, sound insulation material cutting machine.
The company attaches great importance to R&D innovation and excellence, and has won many national invention patents. It has passed ISO9001 international quality system certification, EU CE safety certification and US FAD safety certification, and its products are exported to more than 120 countries and regions.
