Features of corrugated digital cutter vibrating
1. Twin head cutting-off machines boasts of exceptional performance characteristics, including ruggedness and reliability. This machine is the ideal tool for cutting Aluminum, PVC and Curtain-wall profile.
2. Accurate cutting ensures a high accurate re-load position and convenient man operation work.
3. Linear bearing system in moving and feeding device ensures the accurate the machine running and cutting, and stable performance.
4. Right head feeding adopts high helical ball screw-lead motion, with high accuracy and stability.
5. Hydraulic cylinder ensured the stable speed adjusting and saw blade working.
6. Cutting length is controlled by computer control system to locate fast and precisely.
7. CNC Control System for cutting Optimizing with screen output.
8. Automatic angle cutting can be changed in 45° and 90°. Automatic traversing of the moving cutting head and tilting inwards up to 45°.
9. Imported carbide saw blade for a high quality cutting and life.
10. Safety system of shield can ensure the safe operation of man working.
Application of corrugated digital cutter vibrating
Leather, cardboard, fiber glass, corrugated cardboard, honeycomb cardboard, sticker, film, foam board,acrylic board, rebound rubber, rubber cloth, gasket material, garment cloth, footwear material, bags materials, non-woven fabrics, carpets, sponge, PU, EVA, XPE, PVC, PP, PE, PTFE, ETFE and composites.
Specifications
Technical parameters / model |
AOL-1625-ZS6 |
AOL-1825-ZS8 |
AOL-2125-ZS10 |
Accept special model customization |
||
Effective working area |
1600x2500mm |
1800x2500mm |
2100X2500 |
|||
Multi-head optional |
Double head optional efficiency doubled, double gantry optional, double head mutual shift optional, length can be customized |
|||||
Multi-function tool |
Vibrating knife full cutting, high power active round knife, punching tool, pneumatic knife, multi-layer knife |
|||||
safety devices |
Safety devices use infrared sensing, safe and reliable |
|||||
Cutting speed |
200-2000mm/s |
|||||
Cutting thickness |
≤50mm Other thicknesses can be customized according to the material |
|||||
Applicable materials |
Glass fiber, glass fiber cotton, prepreg, carbon fiber, carbon fiber felt, boron fiber, aramid fiber, ceramic fiber, soft glass, PVC, leather leather, sponge composite skin, XPE material, wire ring, leather, soft glass , silicone, rubber material etc composite soft material |
|||||
Material fixing method |
Vacuum partition adsorption |
|||||
Transmission port |
Network port |
|||||
Transmission system |
Yaskawa servo motor, linear linear guide, timing belt, lead screw |
|||||
rated power |
11kw |
|||||
Rated voltage |
380V±10%/220V±10% Optional |
|||||
Control System |
Chinese and English LCD touch screen |
|||||
Operating environment |
Operating environment Temperature 0-40°C Humidity 20%-80%RH |
|||||
软件 |
Automatic nesting software, template entry software（Optional） |
|||||
Support file format |
AI、PLT、DXF、CDRetc |
|||||
Overall size |
3570x2290x1165mm |
3570x2500x1165mm |
3570x25800x1165mm |
|||
Machine details
Our service
Patent certificate
About AOL
AOL is one of the famous professional corrugated digital cutter vibrating manufacturers and suppliers in China，corrugated digital cutter vibrating price is right.If you want to buy it, please contact us.
