Product Details
| Brand Name | RNEDA | Place of Origin | Hebei, China | |
| Model Number | YJLSV,YJLV,YJV,YJV22,YJV32,YJVL32 | Type | Low Voltage | |
| Application | Industrial | Insulation Material | XLPE | |
| Jacket | PVC | Conductor Material | Copper |
Product Description
Chinese supplier cable 4 conductors 50 mm xlpe swa pvc cable for power line
xlpe 11kv power cable price ;5 core power cable;power cable 240 sq mm;35mm power cable;electrical power cable
TOP TEN CABLE MANUFACTURER IN CHINA
LARGEST CABLE MANUFACTUER IN NORTH CHINA
ANNUAL EXPORT VOLUME EXCEED 200MILLION USD
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD'S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE
ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABROTARY
Chinese supplier xlpe swa pvc cable for power line is manufactured according to GB/T12706 (eqvIEC60502), GB/T183802001(eqv. IEC60332),GB/T19216 (IEC60311) and /or the BS, DIN and/or other types of international standards.We can also produce flame retardant cable,water blocking cable,low-smoke low-halogen cable and low-smoke halogen free cable,and also can design and produce cables according to the requirement of our clients
Structure:
Conductor: Solid or stranded copper/Aluminum
Insulation: Cross-linked polyethylene (XLPE) or Polyvinyl chloride (PVC)
Filler: Polypropylene filament with lapped binding tape
Binder: Binding tape
Inner sheath: Polyvinyl chloride (PVC)
Armouring: Single Core: AWA (Aluminium Wire Armour)
Multi Core: SWA (Steel Wire Armour) STA (Steel Tape Armour)
Sheath: Polyvinyl chloride (PVC)
Application :
1,Long term working temperature for the cable with PVC insulated is 70℃;
Long term working temperature for the cable with XLPE insulated is 90℃
2,Short circuit temperature
For PVC insulated cable ,the highest conductor temperature is not more than160℃.(lasting time not over 5 seconds).
For XLPE insulated cable ,the highest conductor temperature is not more than250℃.(Lasting time is not over 5 seconds).
3,Laying temperature not less than 0℃ and the drop height is out of consideration.
4,The cable with chemical stability, anti- acid, anti-alkali, anti-oil, anti-organic solvent, not easy to be burning.
5,Easy for installation, easy bending and light.
a, Number of cores:
1, 2, 3, 3+1, 3+2, 3+3, 4, 4+1, 4+2, 5 and so on.
b, Nominal Section Area(mm2) :1.5 2.5 4 6 10 16 25 35 50 70 95 120 150 185 240 300 400 500 630 800
c,Rated Voltage(KV):3.6/6, 6/6, 6/10, 8.7/10, 8.7/15, 12/20, 18/20, 18/30, 26/35
Type | Designation | Applications | |
YJV | Copper conductor,XLPE insulated, PVC sheathed power cable | For laying indoors,in tunnel or cable trench, unable to bear external mechanical forces. Single core cable is not allowed to laid in magnetic duct. | |
YJLV | Aluminum conductor,XLPE insulated, PVC sheathed power cable | ||
YJY | Copper conductor, XLPE insulated, PE sheathed power cable | ||
YJLY | Aluminum conductor, XLPE insulated, PE sheathed power cable | ||
YJV22 | Copper conductor,XLPE insulated, steel tape armoured,PVC sheathed power cable | For laying indoors,in tunnel in cable trench, or direct in ground,able to bear external mechanical forces. Single core cable is not allowed to laid in magnetic duct. | |
YJLV22 | Aluminum conductor,XLPE insulated, steel tape armoured,PVC sheathed power cable | ||
YJV23 | Copper conductor,XLPE insulated, steel tape armoured,PE sheathed power cable | ||
YJLV23 | Aluminum conductor,XLPE insulated, steel tape armoured,PE sheathed power cable | ||
YJV32 | Copper conductor,XLPE insulated, steel wire armoured,PVC sheathed power cable | For laying indoors,in tunnel cable trench, well or direct in ground,able to bear external mechanical forces and certain pulling force. | |
YJLV32 | Aluminum conductor,XLPE insulated, steel wire armoured,PVC sheathed power cable | ||
YJV33 | Copper conductor,XLPE insulated, steel wire armoured,PE sheathed power cable | ||
YJLV33 | Aluminum conductor,XLPE insulated, steel wire armoured,PE sheathed power cable | ||
1.24 years production experience and 14 years export experience .
2.Products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL etc
3. OEM service available based on official & legal authorization.
4.Strict quality control system.
5.Rapid delivery and feedback Faster lead time than our competitors.
6.Excellent quality with reasonable price.
7. Strong technical support (technical data, drawing, etc.)
8.Professional teamwork service for you actively.
9.Stock available, Free sample is available.
HeBei huatong wires&cables Group Co.,ltd.It was established in 1993, we are JV with Furukawa(Japanese company) for rubber serious cables and JV with Riken(Japanese company) for elevator cables. Besides these,our submersible oil pump cable and shipboard cable are very influential in domestic, and, the traditional cables are also produced such as PVC powercables, XLPE power cables, ABC cables, wires, control cables, screened cables,communication cables, conductors.We areOEM for many USA, Europen, Australia cable company,70% of our products are exported, most customers are from developed countries. We got ISO,UL,TUV,KEMA,CE and many other certifications.
1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.
2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days.
You can use your own express account or prepay us if you do not have an account.
4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep isdelivering 10 kilometers cable within a week. Generally speaking, we suggest that
you start inquiry two months before the date you would like to get the products at your country.
