Silicon Rubber Insulated Silicon Rubber Sheathed Steel Wair Armord Power Cable 5 Core

HeBei huatong wires&cables Group Co.,ltd.

Largest cable manufacture in north China

14 years export experience

With UL,TUV,KEMA,CE,BV,PSB,SABS,GL,NK,KR,ABS ..products certifications

ISO9001,ISO14001,OHSAS18001 system certifications

With authorities testing report

CNAS approval laboratory

Product Description

 Lower Voltage Copper Conductor 5 Core pvc cable 75mm2:

 1 Construction:

  Conductor: copper,stranded

  Insulation:PVC

  Sheath:PVC

  Rated voltage:0.6/1KV

   Certification:ISO9001:2008

2 Standard of products

  The product is suitable for use in power distribution lines or fixed installations with rated power-frequency voltage up to and including 0.6/1KV.

 3 Application:

  For laying indoors, in tunnel or cable trench, unable to bear external mechanical forces, single core cable in magnetic duct is not permissible.

 4 Operating characteristics:

1). Rated power-frequency voltage Uo/U: 0.6/1KV.

2). Max. permissible continuous operating temperature of conductor: 70°C
3). Max. short-circuit temperature of the conductor shall not exceed: (5S maximum duration) 160°C

4). The ambient temperature under installation should not below 0°C

5). The bending radius of a cable should not be less than 15 times of the cable diameter.

5 Type:

 Copper (aluminum) core, PVC insulated and sheathed power cables

Copper (aluminum) core, PVC insulated, PE sheathed power cables
Copper (aluminum) core, PVC insulated, steel tape armoring PVC sheathed power cables
Copper (aluminum) core, PVC insulated, steel tape armoring, PE sheathed power cables
Copper (aluminum) core, PVC insulated, steel wire armoring, PVC sheathed power cables
Copper (aluminum) core, PVC insulated, steel wire armoring, PE sheathed power cables

wooden drum or steel wooden drum or as your request.

Conductor shape  round,fan-shaped

Nominal section  1.5-240mm2

Number cores  1-5core,4+1core,3+2core

Standard    IEC60502

Rated voltage Low voltage

Certificate  ISO9001-2008

Operating working temperature   70 degrees for PVC insulated

Packing length  1500m,2000m,2500m or stipulated by clients.

Exporting regions    Southeast Asia,Africa,Mid East,South America.

 Details Show

   Shipping & Packaging

  Company Introduction

HeBei huatong wires&cables Group Co.,ltd.It was established in 1993, we are JV with Furukawa(Japanese

company) for rubber serious cables and JV with Riken(Japanese company) for elevator cables. Besides these,our submersible oil pump cable and shipboard cable are very influential in domestic, and, the traditional cables are also produced such as PVC powercables, XLPE power cables, ABC cables, wires, control cables, screened cables,communication cables, conductors.We areOEM for many USA, Europen, Australia cable company,70% of our products are exported, most customers are from developed countries. We got ISO,UL,TUV,KEMA,CE and many other certifications.

 Certification

We are one of China top rank cable&wire manufacturer.Our products meet standards of GB, IEC DIN ASTM, JIS, NF, AS/NZS CSA GOST and so on. At thte same time, we have obtained ISO9001,ISO14001,OHSAS18001, UL,CE,KEMA, TUV, Bureau Veritas, Lloyd,IEC,GL,SA,NK,KR certificates.

  FAQ

(1).When can I get the price?

We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.

(2).How can I get a sample to check your quality?

After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.

(3).How long can I expect to get the sample?

After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express

account orprepay us if you do not have an account.

(4).What about the lead time for mass production?

Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking.
