2 Conductors Black and White XLPE Insulation NM-D Cable

2 Conductors Black and White XLPE Insulation NM-D Cable

TOP TEN CABLE MANUFACTURER/EXPORTER IN CHINA
LARGEST CABLE MANUFACTUER IN NORTH CHINA
ANNUAL EXPORT VOLUME EXCEED 200MILLION USD
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD'S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE
ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABROTARY

Description

Two or three copper conductors with 90C XLPE (R90) insulation. Bare bonding wire and overall jacket
of moisture resistant and flame retardant PVC, with FT1 rating.
CSA Spec C22.2 No. 48-M90

Temperature

-25°C to +90°C (except for 3C at -10°C)

Jacket Colours

#14 AWG - White 2 and 3C, Blue 2C
#12 AWG - Yellow
#10 AWG - Orange

#8 & Larger - White

Conductor Insulation Colours
 2 Conductors - Black, White
 3 Conductors - Black, Red, White

Application

For open or concealed wiring in dry or damp locations where not exposed to mechanical injury.
Approved for use with ceiling fixtures.

Specification:

 Standard export drums or soft packages
