Brand Name RNE DA
Place of Origin Hebei, China
Model Number PV
Type Low Voltage
Insulation Material XLPE
Product Description

UL 4703 10 AWG PV SOLAR EXTENSION CABLE with UL Listed



PV wire is rated 600, 1000 or 2000 V, and is suitable for ac and dc systems. This wire is rated 90, 105, 125 or 150°C dry and 90°C wet. PV wire employs 12 AWG - 2000 kcmil stranded aluminum or copper-clad aluminum, or 18 AWG - 2000 kcmil stranded copper, tined copper conductors.



Application
This versatile single-conductor cable is designed to meet the varying needs of the Solar Industry. Applications include connection to module junction boxes; required cable routing in balance of system (BOS) integration.



 UL Type PV (Photovoltaic) UL 4703, 600V, -40°C to 90°C



Single-Conductor: 2kV • Rated 90°C • RHH/RHW-2 • CSA 1kV RPV-90



Product Description:

Single conductor, insulated and non-integrally jacketed, sunlight resistant, photovoltaic wire rated for 90°C wet or dry, 600V for interconnection wiring of grounded and ungrounded photovoltaic power systems as described in Section 630.31 (And other applicable parts of the National Electric Code (NEC), NFPA 70). Ratings only apply to certain gage sizes



 Electrical Characteristics:

--Maximum Operating Voltage: 600 VRMS (UL PV)
Physical Characteristics:
--Temperature Rating: -40°C to 90°C
--Conductor AWG: 12 to 2000 AWG
--Conductor Material: Soft Annealed tinned stranded copper, per ASTM B-33 and EN 60228
--Separator: Paper Tape
--Insulation Material: XLPE  Halogen-free, thermoset, polyolefin specifically, designed for maximum, flexibility
--Jacket Material: Sunlight-Resistant PVC  Black, low smoke, non-halogenated,flame retardant, oil, abrasion, chemical and sunlight resistant cross-linked compound meeting UL 44, UL 854
--Min. Bend Radius: 8x Diameter



Flame Resistance: VW-1

Number of
Strands		 Insulation Thickness  XLPE mm  Outside Diameter mm Allowable Ampacity(Amps) Approximate Net Weight(lbs/1000 ft)
SizeAWG 600V

1000V

2000V

 600V

1000V

2000V

 600V

1000V

2000V

 600V

1000V

2000V

 600V

1000V

2000V
14 19 19 0.06 0.075 4.89 5.61 25 25 24 28
12 19 19 0.06 0.075 5.37 6.05 30 30 33 38
10 19 19 0.06 0.075 5.99 6.6 40 40 47 52
8 7* 7* 0.075 0.085 7.52 7.95 55 55 74 78
6 7* 7* 0.075 0.085 8.48 8.86 75 75 108 113
4 7* 7* 0.075 0.085 9.7 10.06 95 95 161 166
3 7* 7* 0.075 0.085 10.41 10.77 110 110 197 203
2 7* 7* 0.075 0.085 11.23 11.58 130 130 243 249
1 19 19 0.095 0.105 13.16 13.49 150 150 313 320
1/0 19 19 0.095 0.105 13.97 14.48 170 170 380 389
2/0 19 19 0.095 0.105 15.09 15.6 195 195 476 484
3/0 19 19 0.095 0.105 16.36 16.87 225 225 590 599
4/0 19 19 0.095 0.105 17.78 18.29 260 260 732 742
250 37 37 0.11 0.12 19.35 19.86 290 290 873 884
300 37 37 0.11 0.12 20.67 21.18 320 320 1035 1047
350 37 37 0.11 0.12 21.87 22.38 350 350 1198 1210
400 37 37 0.11 0.12 22.99 23.5 380 380 1358 1371
500 37 37 0.11 0.12 25.04 25.55 430 430 1680 1694
600 61 61 0.125 0.135 29.03 29.54 475 475 2057 2073
750 61 61 0.125 0.135 31.7 32.21 535 535 2508 2525
1000 61 61 0.125 0.135 35.61 36.12 615 615 3303 332
