EN50618 Tinned Copper Conductor 4mm 6mm Solar Panel Cable
- Tianjin port Qingdao port Shang hai port
- T/T Credit Card
You May Like
-
UL Listed Electrical Wire 600v THHN Wire 4 AWG THHN THHN THW Wire and Cable
-
PVC Insulation Nylon Sheathed THHN / THWN Electrical Wire
-
Hot Sell UL83 THHN,THWN,THWN-2,TW,THW,THW-2,THHW Nylon Sheath Wire
-
UL Listed Electrical Wire THHN THW THWN Wire and Cable
-
6AWG TW/THW/THW-2 Thermoplastic-insulate Wire and Cable
-
UL Listed 600v PVC/thermoplastic-insulated Electric Wire THHN/THWN/THW
Product Details
| Brand Name | RNEDA | Place of Origin | Hebei, China | |
| Model Number | solar panel cable | Type | Low Voltage | |
| Insulation Material | XLPE | |||
| Conductor Material | Copper |
Product Description
LARGEST CABLE MANUFACTUER IN NORTH CHINA
ANNUAL EXPORT VOLUME EXCEED 200MILLION USD
WITH UL,TUV,KEMA,CE,BV,PSB,SABS,LLOYD'S,GL,NK,KR,ABS PRODUCTS CERTIFICATIONS
WITH TUV TYPE TESTING REPORT
WIDE PRODUCTS RANGE
ISO9001,ISO18001,OHSAS18001 SYSTEM CERTIFICATIONS
CNAS APPROVAL LABROTARY
EN50618 tinned copper conductor 4mm 6mm solar panel cable
1.Rating:Voltage:
AC600/1000V DC1000/1800V Temperature:-40°C-- 125°C
4.General characteristics:
1.Double insulation,electron beam cross-linked
2.Excellent resistance to UV, water, ozone, fluids, salt, general Weathering
3.Excellent resistance to abrasion
4.Halogen free,flame retardant,low toxicity
5.Excellent flexibility and stripping performance
6.High current carrying capacity
7.TUV and UL approved
Specification:
Cross Section (mm²) | Conductor Construction (n/mm) | Conductor Stranded OD.(mm) | Insulation Min.Wall Thickness(mm) | Sheath Min.Wall Thickness(mm) | Cable OD.(mm) | Conductor Max.Resistance AT20°C (Ω/km) | Current Araaing Capacity AT 60°C(A) |
1.5mm² | 30/0.25 | 1.58 | 0.67 | 0.73 | 4.90 | 13.3 | 30 |
2.5mm² | 50/0.25 | 2.02 | 0.67 | 0.73 | 5.45 | 7.98 | 41 |
4mm² | 56/0.30 | 2.60 | 0.67 | 0.73 | 6.10 | 4.95 | 55 |
6mm² | 84/0.30 | 3.42 | 0.8 | 0.80 | 7.20 | 3.30 | 70 |
10mm² | 142/0.30 | 4.56 | 0.9 | 0.90 | 9.00 | 1.91 | 98 |
16mm² | 228/0.30 | 5.60 | 1.00 | 0.90 | 10.20 | 1.21 | 132 |
25mm² | 361/0.30 | 6.95 | 1.19 | 0.92 | 12.00 | 0.780 | 176 |
35mm² | 276/0.40 | 8.74 | 1.20 | 1.00 | 13.80 | 0.554 | 218 |
Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220,000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billionYuan.Now there are more than 800 employers in our company, among which more than 150 are technicians. With the continuous efforts from all the employers, Hebei Huatong Wires and Cables Group Co., Ltd has realized great development to become a modern enterprise and one of the comprehensive, largescale enterprises in domestic wire and cable industry. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria,Congo, Middle East and Southeast Asia and so on.


Other certificates
Our laboratory center are authorized by both of ILAC (International Laboratory Accreditation Cooperation)&CNAS(China National Accreditation Service for Conformity Assessment), so the testing results in our labs can be accepted by the international countries belong to the above organizations.


(1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please
call us or tell us in your e-mail so that we will regard your inquiry priority.
(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight
charge should be paid.
(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 1-2
days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account orprepay us if you do not have an account.
(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is
delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
