High Quality and Low Price Hydraulic Rock Core Drilling Machine

Name: High Quality and Low Price Hydraulic Rock Core Drilling Machine
Brand: HuaxiaMaster
SKU: 160656293

US$ 4500 - 5000 MOQ: 1 Set

Key Specifications

Brand Name:

HuaxiaMaster

Place of Origin:

China

Model Number:

XY-200

Shandong Master Machinery Group Co.,Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

3 days

Brand Name HuaxiaMaster

Place of Origin China

Model Number XY-200

Type Core Drilling Rig

Certification ISO

After-sales Service Provided Engineers available to service machinery overseas

Warranty one year

Weight 760kg

Dimension(L*W*H) 2.75*0.95*1.60

Power Type Diesel

Voltage 220

Usage Water Well

Condition New

Power(W) 15kw

1. Application range of XY-200 core drilling rig

Geological survey, geophysical exploration, road and high-rise building foundation exploration, wells, blasting holes and other drilling projects.

2. Parameters of XY-200 core drilling machine

Maximum opening diameter	400mm
Maximum borehole depth	200m
Diameter of the end hole	75mm
Borehole dip angle	90~75°
Machine overall size	2.750.951.60m
Drill pipe diameter	50mm
Weight of drill rig diameter of drill pipe (without power)	760kg
A vertical scroll of painting
Shaft rotation speed	71/142/310/20r/min
Vertical axis stroke	450mm
Windlass
Maximum lifting weight of single rope	2008Kb
Drum lifting speed	17/35/75/160 rm/s
Wire rope diameter:	13mm
Wire rope capacity	35mm
Width of sluice	70mm
Mud pump
Type: horizontal single cylinder double action	flow：180L/min
Maximum pressure	1.5Mpa
Working pressure	0.7Mpa
Inlet Size	50mm
Outlet pipe diameter	45mm
Power
Diesel oil	22HP
Rated speed	2200r/min
Electric machinery	15kw
Rated speed	1460r/min
