200mm diameter galvanized rectangular steel pipe prices
- 15000 Ton / Tons per Month
- Tianjin
- T/T Credit Card
- GI steel hollow sections 100x100, gi steel box sections, galvanized welded square steel pipe and tube
- 2017 Hot Selling Carbon Steel Tube, Galvanized Steel Rectangular Tube size 60x40
- GI steel tube, Q195 pre galvanized square steel pipe, galvanised fence tubing size 20x20
- GI square steel pipe tube, hot dipped galvanized square hollow section, gi rectangular steel box section
- 1.6 mm 2.0mm thickness galvanized steel pipe, 40x40 galvanized square metal fence posts, galvanized square section
- EN10219 square galvanized steel pipe, 20x40 rectangular steel tube, shs rhs square tube
Product Details
Place of Origin: | Tianjin, China | Thickness: | 1.0, 5.0 | ||
Application: | Structure Pipe | Surface Treatment: | Galvanized | Technique: | ERW |
Alloy Or Not: | Non-alloy | ||||
Secondary Or Not: | Non-secondary |
Product Description
- What is the HDG ERW Square and rectangular hollow section?
RHS and SHSare welded structural grade tubing,depending on its size and wall thickness. Either grade is ideal for all structural applications, general fabrication, manufacturing and repairs.
Square hollow section is widely used in industrial maintenance, agricultural implements, transportation equipment, truck beds, trailers, frames, etc. Its box-shape configuration allows for much greater strength and rigidity compared to angles or channels.
This steel shape is easy to weld, cut, form and machine with the proper equipment and knowledge. Metals Depot stocks hundreds of sizes of square tube at wholesale prices in ready to ship precut and mill lengths or you can order just what you need custom Cut to Size in any quantity.
- Detailed Images
• Specification of square hollow section we can supply
Size | W.T | Size | W.T | Size | W.T | Size | W.T | Size | W.T |
mm | mm | mm | mm | mm | mm | mm | mm | mm | mm |
10x10 | 0.6~0.8 | 35x35 | 1.0~4.0 | 60x60 | 1.5~6.0 | 110x110 | 3.0~6.0 | 160x160 | 4.0~8.0 |
12x12 | 0.6~0.8 | 38x38 | 1.0~5.0 | 70x70 | 2.0~6.0 | 115x115 | 3.0~6.0 | 180x180 | 4.0~8.0 |
13x13 | 0.6~2.0 | 40x40 | 1.0~6.0 | 80x80 | 2.0~6.0 | 120x120 | 3.0~6.0 | 200x200 | 5.0~10.0 |
15x15 | 0.7~2.0 | 42x42 | 1.2~6.0 | 85x85 | 2.0~6.0 | 125x125 | 3.0~6.0 | ||
16x16 | 0.7~2.0 | 45x45 | 1.2~6.0 | 90x90 | 2.0~6.0 | 130x130 | 3.0~6.0 | ||
20x20 | 1.0~3.0 | 48x48 | 1.2~6.0 | 95x95 | 2.0~6.0 | 135x135 | 4.0~14.0 | ||
25x25 | 1.0~3.0 | 50x50 | 1.5~6.0 | 100x100 | 2.0~6.0 | 140x140 | 4.0~8.0 | ||
30x30 | 1.2~4.0 | 55x55 | 1.5~6.0 | 105x105 | 2.0~6.0 | 150x150 | 4.0~8.0 |
• Specification of Rectangular hollow section we can supply
Size | W.T | Size | W.T | Size | W.T | Size | W.T | Size | W.T |
mm | mm | mm | mm | mm | mm | mm | mm | mm | mm |
20x10 | 0.7~2.0 | 70x25 | 1.2~6.0 | 100x90 | 2.0~6.0 | 130x50 | 2.0~6.0 | 150x110 | 2.0~6.0 |
20x14 | 0.7~2.0 | 70x30 | 1.2~6.0 | 110x25 | 2.0~6.0 | 130x60 | 2.0~6.0 | 150x250 | 3.0~12.0 |
20x15 | 0.7~2.0 | 70x40 | 1.2~6.0 | 110x30 | 2.0~6.0 | 130x70 | 2.0~6.0 | 150x300 | 2.0~6.0 |
26x13 | 0.7~2.0 | 70x50 | 2.0~6.0 | 110x40 | 2.0~6.0 | 130x80 | 2.0~6.0 | 160x40 | 2.0~6.0 |
30x10 | 0.7~2.0 | 70x60 | 2.0~6.0 | 110x50 | 2.0~6.0 | 130x90 | 2.0~6.0 | 160x50 | 2.0~6.0 |
30x15 | 0.7~2.0 | 80x20 | 1.2~4.0 | 110x60 | 2.0~6.0 | 130x100 | 2.0~6.0 | 160x60 | 2.0~6.0 |
30x20 | 0.8~2.0 | 80x25 | 1.2~6.0 | 110x70 | 2.0~6.0 | 130x110 | 2.0~6.0 | 160x70 | 2.0~6.0 |
40x10 | 0.8~2.0 | 80x30 | 1.2~6.0 | 110x80 | 2.0~6.0 | 130x120 | 2.0~6.0 | 160x80 | 2.0~6.0 |
40x15 | 1.0~2.0 | 80x40 | 1.2~6.0 | 110x90 | 2.0~6.0 | 140x30 | 2.0~6.0 | 160x90 | 2.0~6.0 |
40x20 | 1.0~2.5 | 80x50 | 2.0~6.0 | 110x100 | 2.0~6.0 | 140x40 | 2.0~6.0 | 160x100 | 2.0~6.0 |
40x25 | 1.0~2.5 | 80x60 | 2.0~6.0 | 110x140 | 4.0~6.0 | 140x50 | 2.0~6.0 | 180x40 | 2.0~6.0 |
40x30 | 1.0~2.5 | 80x70 | 2.0~6.0 | 120x25 | 2.0~6.0 | 140x60 | 2.0~6.0 | 180x50 | 2.0~6.0 |
50x11 | 1.0~2.0 | 90x25 | 1.2~6.0 | 120x30 | 2.0~6.0 | 140x70 | 2.0~6.0 | 180x60 | 2.0~6.0 |
50x15 | 1.0~3.0 | 90x30 | 1.2~6.0 | 120x40 | 2.0~6.0 | 140x80 | 2.0~6.0 | 180x70 | 2.0~6.0 |
50x20 | 1.0~3.0 | 90x40 | 2.0~6.0 | 120x50 | 2.0~6.0 | 140x90 | 2.0~6.0 | 180x80 | 2.0~6.0 |
50x25 | 1.0~3.0 | 90x50 | 2.0~6.0 | 120x60 | 2.0~6.0 | 140x100 | 2.0~6.0 | 190x40 | 2.0~6.0 |
50x30 | 1.0~3.0 | 90x60 | 2.0~6.0 | 120x70 | 2.0~6.0 | 140x110 | 2.0~6.0 | 190x50 | 2.0~6.0 |
50x40 | 1.0~3.0 | 90x70 | 2.0~6.0 | 120x80 | 2.0~6.0 | 140x120 | 2.0~6.0 | 190x60 | 2.0~6.0 |
60x15 | 1.0~3.0 | 90x80 | 2.0~6.0 | 120x90 | 2.0~6.0 | 150x30 | 2.0~6.0 | 190x70 | 2.0~6.0 |
60x20 | 1.0~3.0 | 100x25 | 2.0~6.0 | 120x100 | 2.0~6.0 | 150x40 | 2.0~6.0 | 200x40 | 2.0~6.0 |
60x25 | 1.0~4.0 | 100x30 | 2.0~6.0 | 120x110 | 2.0~6.0 | 150x50 | 2.0~6.0 | 200x50 | 2.0~6.0 |
60x30 | 1.0~4.0 | 100x40 | 2.0~6.0 | 120x130 | 4.0~6.0 | 150x60 | 2.0~6.0 | 200x60 | 2.5~6.0 |
60x40 | 1.2~6.0 | 100x50 | 2.0~6.0 | 120x140 | 4.0~6.0 | 150x70 | 2.0~6.0 | 200x100 | 3.0~13.0 |
60x50 | 1.2~6.0 | 100x60 | 2.0~6.0 | 120x200 | 4.0~6.0 | 150x80 | 2.0~6.0 | 200x300 | 3.0~13.0 |
• How to produce HDG SHS and RHS tubing?
Hot-dip galvanizing is a form of galvanization. It is the process of coating iron or steel with a thin zinc layer, by passing the steel through a molten bath of zinc at a temperature of around 860 °F (460 °C).
When exposed to the atmosphere, pure zinc reacts with oxygen to form zinc oxide, which further reacts with carbon dioxide to form zinc carbonate, a dull grey, fairly strong material that stops further corrosion in many circumstances, protecting the steel below from the elements. The process of hot-dip galvanizing results in a metallurgical bond between zinc and steel with a series of distinct iron-zinc alloys.
• What can we do with hot dipped square & rectangular tube?
Hot dipped galvanized rectangular hollow section is widely used all over the world,and we mainly used this square tube in these indusrty area,such as:
• Glass curtain wall;
• power tower;
• communication grid;
• water and gas transmission;
• wire casing;
• houses;
• bridges;
• metal structures;
- Company Information
Our company covers an area of 48,800 square meters and we are specialized in exporting.We have ISO:9001,14001,18001certifications and SGS, TuVcertifications.Presently we have four production lines,260 staff and 36 senior engineers,which make our product capacity reaches 100,000 tons.Since our company was founded, we have won national qualified products, quality entrusted unit, model unit, and China Enterprise Credit Association AAA Grade Credit Enterprise.
