Help CenterJiaoxi Quality Assurance 20w Metal Fiber Laser Marking Machine
Related Products
-
Jiaoxi Quality Assurance 30w Metal Fiber Laser Marking MachineUS$ 2500 - 5000MOQ: 1 Set -
20W Split Type Fiber Laser Marking Machine for Sale Marking Metal and Non-metalUS$ 2500 - 5000MOQ: 1 Set
-
30W Split Type Fiber Laser Marking Machine for Sale Marking Metal and Non-metalUS$ 2500 - 5000MOQ: 1 Set
-
Portable High Quality Auto Focus Laser Marking Machine 20w FiberUS$ 2500 - 5000MOQ: 1 Set
-
Portable High Quality Auto Focus Laser Marking Machine 30w FiberUS$ 2500 - 5000MOQ: 1 Set
Advantage
Fiber laser marking machine is the new generation marking system developed by our company with advanced laser technique, it adopts fiber laser to output laser and achieves to marking function after high speed scanning oscillating mirror system. It has higher photoelectric transfer
efficiency. This machine adopts air cooling way and the whole machine is mall, the output
beam is qualified, high reliability.
Applicable materials
All metals and some non metal materials.
Applicable industry
Mainly used to mark on various plastic buttons and electric devices, to mark code on CMOS chip,
color paper and food package. It can also be used in the scope with high requirements, such as
clock, jewelry, module, bitmap marking etc..
Technical Parameters
Model |
JX-TSBB-Y20/30 |
Laser power |
20W / 30W |
Laser type |
IPG(imported/Made in China) |
Max marking speed |
300 characters/s, height of character 1 mm |
Graphic format supported |
PLT, BMP, JPG, PNG, TIP, PCX, TGA, ICO, DXF |
Beam quality |
2 |
Power stability(8h) |
|
Pulse repeat frequency |
20-60KHZ |
Whole machine power |
|
Mini line width |
50um |
Mini character |
3mm |
Laser wavelength |
1064nm |
Oscillating mirror area |
100*100mm |
Cooling way |
Air cooling |
Working voltage |
220v±10% |
Working temperature |
5-35℃ |
Net/gross weight(kg) |
75/115kg |
Machine dimension |
600*620*1320mm |
Package size |
700*720*1470mm |
