| Name |
aisi304l stainless steel tube | |||||
| Standard | GB12770,GB12771,ASTM A249,ASTM A269,ASTMA270,ASTMA312,ASTMA554,JIS G 3463 | |||||
| Grade | 201,202,304,316,316L,430 | |||||
| Main Material | a) 201 (Ni0.8%-1%) | |||||
| b) 202 (Ni: 3.5%-4.5%) | ||||||
| c) 304 (Ni: 8% Cr: 18%) | ||||||
| d) 316 (Ni: 10% Cr: 18%) | ||||||
| Thickness | 0.5-20.0mm | |||||
| Length | as customers’ request | |||||
| b)Thickness; +/-0.05mm | ||||||
| c)Length;+/-5mm | ||||||
| Application | mainly used in decoration, for fluid and gas transport; structural and machining | |||||
| Test | Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT | |||||
| Chemical Composition of Material | Composition | 201 | 202 | 304 | 316 | 430 |
| C | ≤0.15 | ≤0.15 | ≤0.08 | ≤0.08 | ≤0.12 | |
| Si | ≤1,00 | ≤1,00 | ≤1,00 | ≤1.00 | ≤1.00 | |
| Mn | 5.5-7.5 | 7.5-10 | ≤2.00 | ≤2.00 | ≤1.00 | |
| P | ≤0.06 | ≤0.06 | ≤0.045 | ≤0.045 | ≤0.040 | |
| S | ≤0.03 | ≤0.03 | ≤0.030 | ≤0.030 | ≤0.030 | |
| Cr | 12.5-14.5 | 15-18 | 18-20 | 16-18 | 16-18 | |
| Ni | 0.8-1.5 | 4-6 | 8-10.5 | 10-14 | ||
| Mo | 2.0-3.0 | |||||
| Mechanical Proper | Material Item | 201 | 202 | 304 | 316 | |
| Tensile Strength | ≥535 | ≥520 | ≥520 | ≥520 | ||
| Yield Strength | ≥245 | ≥205 | ≥205 | ≥205 | ||
| Extension | ≥30% | ≥30% | ≥35% | ≥35% | ||
| Hardness(HV) | <253 | <253 | <200 | <200 | ||
| aisi304l stainless steel tube | |
| We can supply a variety of stainless steel tubes. | |
| 1) Material:300 series(304,304L,316,316L),200 series(201) | |
| 2) Process method: Cold drawn, Pickling, Polishing | |
| 3) Standards: ASTM A554 | |
| 4 )Surface: Titanium finish,600#-1000#, 400#, 320#satin,180# HL and 2B | |
5)Innner packing: every tube sleeved by plastic bag; Outer packing: Bundle,steel crate or according to customers' requests. | |
6)round tube size:12.7mm~127mm Single slot round tube:OD25.4x(12x12)~OD76.2x25x25 | |
Square tube size:10x10~150x150mm Rectangular tube size:10x30~120x60mm | |
Oval tube:20x40~60x120mm oval slot tube ,square slot tube and 90 degree tube size according to customers' requests. | |
Stainless steel pipes & tubes are widely used for many are as follows: | |
| 1. decoration, door, windows, handrail, ladder, furniture and so on. | |
| 2. heat-exchanger, condenser, boiler pipeline parts and superheater. | |
| 3. pressure pipelines, petroleum transmission pipes, petrolchemical industry pipes, liquid delivery pipe, water pipelines. | |
| 4. milk transmission, sugar factory, dairy, sanitation, bathroom pipes and other sanitary areas. | |
| 5. other industry pipes which need the corrosion-resistance and pressure material. | |
| 6. any other pipelines. | |
Size Range | O.D. 1-20mm |
| W.T. 0.8-10mm |
Standard | ASTM/A240, A312 |
Material | 304, 304L,310s 316, 316L,321,201,202 |
Surface | Stain Direction / Mirror / Custom (SSS / PSS / PVD),G400# satin finish or G600# mirror finish |
Length | Max: 25metres |
Talerance: | a)Outer diameter:± 0.05mm |
b)Thickness: ±10% of wall thickness | |
c)Length: ± 0.0-4.5mm | |
Application | construction upholstery, decorating lighting fitting piece, fluid pipeline, irregular shape tube, duplexing tube |
name | aisi304l stainless steel tube |
Size Range | O.D. 1-20mm x1-20mm |
| W.T. 0.8-10mm |
Standard | ASTM/A249, A312, GB151, GB12771, HG20537 |
Material | Grade: 304, 304L,310s 316, 316L,321,840 |
Length | Max: 25metres |
Talerance: | a)Outer diameter:± 0.05mm |
| b)Thickness: ±10% of wall thickness |
| c)Length: ± 0.0-4.5mm |
