Help CenterPS9016 PID Intelligent Pressure Controller
Related Products
-
PS1016 Series Intelligent Pressure IndicatorUS$ 120 - 150MOQ: 1 Set -
PT555 Intelligent Melt Pressure GaugeUS$ 200 - 260MOQ: 1 Piece
-
PT135C Mechanical Melt Pressure GaugeUS$ 120 - 220MOQ: 1 Piece
-
Flexible Plastic Extruder High Temperature Melt Pressure TransducerUS$ 200 - 280MOQ: 1 Piece
-
Explosion Proof Melt Pressure Transmitter PTF1316BUS$ 240 - 260MOQ: 1 Piece
Product Description
Pressure Controller Introduction
PS9016 series programmable intelligent digital pressure controller is the latest brand new pressure instrument. It is especially suitable for melt pressure measurement and control areas with its superior compatibility and cost performance. And it can be used withPT series melt pressure sensor / transmitter to support the high-temperature melt, fluid, and the accurate measurement of gas pressure perfect control widely in petrochemical, textile and chemical fiber, plastics, rubber, non-woven fabric, machinery and other equipment industries. It is with a full-featured, high reliability, stability, appearance, and strong anti-interference characteristics to ensure the long-term stability of the system work.
Pressure Controller Performance
1. Pressure range and decimal point location can be programmed;
2. Single PID pressure control signal output, providing multiple output signals (eg: 0~10V, 0~5V, 0~20mA, 4~20mA,), programmable;
3. Two alarm outputs, multiple alarm modes can be programmed;
4. Automatic calibration and panel error correction function;
5. Compatible with multiple pressure transducer and transmitter input signal;
6. Four digital displays with two layers and double colors and 20 segments electronic bar indicate the output power;
7. Provide RS485 computer communication interface (optional);
8. Triple combination of anti-jamming technology to ensure more accurate;
9. More than 20,000 hours of trouble-free operation;
10. with manual and automatic Switching feature to control output power.
Pressure Controller Technical Index
Pressure range |
0~1500bar;0~20000psi |
Power supply |
85~265VAC;24VDC;110VAC;220VAC;240VAC |
PID output signal |
0~5V,1~5V,0~10V,0~10mA,0~20mA,4~20mA(Programmable ) |
Alarm |
Two-way upper and lower limited relay alarm |
Relay contact output |
250VAC,5A |
Input signal |
2.0mV/V,3.33mV/V,0~20mA,4~20mA,0~10V,0~5V,1~5V |
Communication |
RS485 |
Mailing Address |
0001~0255 |
Communication baud rate |
2400bps,4800bps,9600bps,19200bps,38400bps |
Inner resolution |
32000 |
Ambient temperature |
-10 C~50 C |
Ambient humidity |
|
Our Services
· 5 Year warranty (First two years are free to repair,other 3 years are chargeable)
· OEM service available (Products supplied without any logo,you could put your own logo on it)
· Technical support (We are available to solve any problems you have on sensors any time)
