PT1246 Melt Pressure Transducer M14*1.5

This series high-temperature melt pressure sensor / transmitter are mainly used in conventional for
measurement of high temperature melt pressure. They are used in petrochemical industry, chemical textile, plastics and rubber industries, new materials and other industries, with advantage of high accuracy, stable, big output, strong dynamic performance advantages, good generality etc.

Product Details

1 A variety of connectors to facilitate the user to select 5PIN or 6PIN;

2 1/2 "-20, M14 x 1.5, M22 x 1.5, G3 / 4" A variety of mounting dimensions to facilitate the user to select;

3 Accuracy: ± 0.5% FS, ± 1.0% FS (default);

4 Output signal: Pressure sensors; 2.0mV / V, 3.0mV / V, 3.33mV / V; Pressure transmitter: 1 ~ 5V, 0 ~ 10V, 0 ~ 20mA, 4 ~ 20mA;

5 Temperature drift: ≤ 0.3MPa/100 ℃;

6 Probe Max Temperature: 300 ℃ or 400 ℃;

7 corrosion resistant coating to extend the service life of 3 to 5 times; (optional)

8 Thermometric Config:

Thermocouple: E, J, K type, etc.,

Thermal Resistance: Pt100 etc. (Optional)

Product Parameters

Example1:

PT124-50MPa-M14-150/370-2.0mV/V

Note:

Product design Model "PT124".
Function code "Null" stands for melt pressure transducer.
Coating code "Null" stands for without coating .

Pressure range: 0 ~ 50MPa
Thread size : M14* 1.5.

Rigid stem length:150mm /370mm.
Pressure output signal: 2.0mV/V.
